ROOF PANEL & BACK PANEL

Parts diagram

63071FRAME SUB-ASSY, BACK DOOR OPENING, UPPER

main63071-26090i199907-200501

main63071-26120i199907-200205

main63071-26130i199508-199510

main63071-26150i199510-199708

63102REINFORCEMENT SUB-ASSY, ROOF PANEL, FRONT

main63102-26080i199508-199907

63102APANEL SUB-ASSY, WINDSHIELD HEADER

main63102-26060i199508-199708

main63102-26070i199508-199907

main63132-26070i199907-200501

63103AREINFORCEMENT SUB-ASSY, ROOF PANEL

main63103-26110i199508-199708

main63142-26040i199907-200205

63111PANEL, ROOF

main63100-26110i199907-200501

main63101-26130i199907-200205

main63101-26150i199508-199708

main63101-26420i199708-199804

main63111-26030i199508-199608

main63111-26100i199907-200205

main63111-26120i199508-199708

main63111-26180i199608-199708

main63111-26340i199708-199804

63141GREINFORCEMENT, ROOF PANEL, NO.1

main63103-26120i199508-199708

main63141-26110i199706-199708

main63141-26160i199907-200501

63141HREINFORCEMENT, ROOF PANEL, CENTER

main63141-26100i199508-199708

main63143-26060i199907-200205

63142REINFORCEMENT, ROOF PANEL, NO.2

main63142-26030×2i199907-200501

main63142-26040i199508-199708

63142AREINFORCEMENT, ROOF PANEL, NO.2

main63142-26030i199508-199708

main63142-26040i199508-199708

63143AREINFORCEMENT, ROOF PANEL

main63143-26060i199508-199708

63143BREINFORCEMENT, ROOF PANEL, NO.3

main63142-26030i199508-199708

main63144-26010i199508-199708

63187ABRACKET, ROOF RACK, REAR

main63107-26030×6i199508-199608

main63107-26050×6i199907-200205

63347CPAD, ROOF SILENCER, NO.7

main63347-26010i199508-199907

9017906164

main90179-06164

14 parts on this diagram · 6 diagrams in section
