FRONT BUMPER & BUMPER STAY

0001 1 0002 1 0003 1 0004 1 0005 1

52053PAD SUB-ASSY, FRONT BUMPER

main52421-95701iTM20..GXL,XL197910-198001

main52421-95702iTM20..GXL,XL198001-198210

52105STAY SUB-ASSY, FRONT BUMPER, RH

main52201-95701iKM20..V4D..SUP..WT198011-198011

SATELLITE 80

52106STAY SUB-ASSY, FRONT BUMPER, LH

main52202-95701iKM20..V4D..SUP..WT198011-198011

SATELLITE 80

52111BUMPER ASSY, FRONT

main52101-87405iKM20..TR197910-198210

main52101-95704iKM20,TM20..(HRF,SRF)..(DLX,STD,SUP)197910-198210

main52101-95711iCM2#,KM21,YM20,25..TR,V198210-198609

main52111-29395iKM20..V4D..SUP..WT198011-198011

SATELLITE 80

main52111-29405iTM20..GXL,XL197910-198001

main52111-29406iTM20..GXL,XL198001-198210

main52111-95708iCM20,YM21..07S,08S,09S198210-198508

BLACK

main52111-95714iCM20,YM21..FXV,GXL198210-198508

SILVER-M

52112DEXTENSION, FRONT BUMPER, RH

main52011-29015iKM20,TM20..DLX,GXL,STD,SUP,XL197910-198210

main52117-95701iCM20,YM21..SW198308-198508

52113DEXTENSION, FRONT BUMPER, LH

main52012-29015iKM20,TM20..DLX,GXL,STD,SUP,XL197910-198210

main52118-95701iCM20,YM21..SW198308-198508

7554TOOL BOX & LICENSE PLATE BRACKET

→ Go to FIG 75-54

9011208023

main90112-08023

9011208028

main90112-08028

9011908126

main90119-08126

9017908123

main90179-08123

9046810011

main90468-10011

9165140814

main91651-40814

9166540825

main91665-40825

9411040800

main94110-40800

15 parts on this diagram · 5 diagrams in section
