RADIO RECEIVER & AMPLIFIER & CONDENSER

0001 1 0002 1SUPER LIVE SOUND 0003 1

86120RECEIVER ASSY, RADIO

main86120-12750iAE10#,CE100,104..GT,SEG,SEL; AE101..SJ199305-199405

main86120-12751iAE10#,CE100,104..4DS..(GT,SEG,SEL)199405-199505

main86120-12760iAE101..3DS..GT199305-199405

main86120-12761iAE101..3DS..GT199405-199505

main86120-12770iAE100,104,CE100,104,EE101..SEL,XE; AE101..SEG199305-199405

main86120-12771iAE10#,CE100,104,EE101..SEG,SEL,XE199405-199505

main86120-12780iAE10#,CE100,104,108,EE101,108..DX,G,GT,L,LT,LX,SEL,SJ,XE199205-199305

main86120-12870iAE100,104,CE10#,EE10#..CTD,DX,DXJ,GL,L,LX199106-199505

main86120-12890iCE108,EE108199305-199508

main86120-16600iAE100,101,104,CE100199505-199705

main86120-16610iAE100,101,104,CE100,101199705-200008

main86120-1A050iAE100..WG199109-199305

main86120-1A051iAE100..WG199405-199505

main86120-1A100iCE108; EE103..GL; EE104199401-199505

main86120-27010iAE109,CE102,105,106,107,108,109,EE10#199505

main86120-28240iCE108; EE103..GL; EE104199505-199705

main86120-32480iAE109,CE10#,EE10#200008

86203DWIRE, STEREO COMPONENT, NO.1

main86203-12260iAE10#,CE100,104,EE101..(4DS,WG)..(G,GT,LT,SEL,XE); AE101..SEG199106-199305

main86203-12280iCE108; CE109..GL; EE104199401-199508

main86203-12300iAE100,101,104,CE100,101199705-200008

86203HWIRE, STEREO COMPONENT, NO.2

main86203-12270iAE10#,CE100,104,EE101..(4DS,WG)..(G,GT,LT,SEG,SEL,XE)199106-199305

86211BRACKET, RADIO, NO.1

main86211-12250iAE10#,CE10#,EE10#199106

LOWER

main86211-12270iAE10#,CE10#,EE10#199106

UPPER

86212BRACKET, RADIO, NO.2

main86212-12230iAE10#,CE10#,EE10#199106

LOWER

main86212-12250iAE10#,CE10#,EE10#199106

UPPER

86270ADISC PLAYER ASSY

main86270-12040iAE10#,CE100,104,EE101..(4DS,WG)..(G,GT,LT,SEG,SEL,XE)199106-199305

main86270-20040iAE10#,CE100199505-199603

main86270-20050iAE100,101,104,CE100199603-199705

86280AMPLIFIER ASSY, STEREO COMPONENT

main86280-12100iAE10#,CE100,104,EE101..4DS..(GT,SEG,SEL,XE)199106-199305

main86280-12140iAE100,101,104,CE100..WG199109-199705

main86280-12150iAE101..3DS..GT; AE101..SJ199305-199405

main86280-12170iAE101..3DS..GT199305-199405

main86280-12220iAE100,101,104,CE100,101199705-200008

9014950032

main90149-50032

9015350010

main90153-50010

9015950238

main90159-50238

10 parts on this diagram · 3 diagrams in section
