DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1 0004 1

42601WHEEL, DISC

main42611-0W030iCXM10,SXM10199609-200008

14X6JJ,TYPE A:REFER TO ILLUSTRATION

main42611-44010iCXM10,SXM10199609-200008

14X6JJ,TYPE B:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-0W030iCXM10,SXM10199609-200008

14X6JJ,TYPE A:REFER TO ILLUSTRATION

main42611-44010iCXM10,SXM10199609-200008

14X6JJ,TYPE B:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01058iCXM10,SXM10199609-200008

TYPE A:REFER TO ILLUSTRATION

main90942-01082iCXM10,SXM10199609-200008

TYPE B:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009iCXM10,SXM10199609-200008

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iCXM10,SXM10199609-200008

42652TIRE

main42652-44020iCXM10,SXM10199609-200008

195/65R14

42652ATIRE (FOR SPARE)

main42652-44020iCXM10,SXM10199609-200008

195/65R14

7 parts on this diagram · 4 diagrams in section
