DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1 0004 1

42601WHEEL, DISC

main42611-02430×4iCDE120..UKP..DCR;ZZE121..UKP..RHD..SOL;ZZE121..UKP..WG..4FC..TERRA; ZZE120..UKP;ZZE121..UKP..LHD..SOL;ZZE121..UKP..5F..TERRA;ZZE121..UKP..SED..4FC..TERRA200201-200406

15X6JJ, #,TYPE B:REFER TO ILLUSTRATION

main42611-02450×4iZZE120..UKP..TERRA200406

14X5.5JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-02460×4iCDE120..UKP..DCR;ZZE121..UKP..RHD..SOL;ZZE121..UKP..WG..4FC..TERRA; ZZE120..UKP;ZZE121..UKP..LHD..SOL;ZZE121..UKP..5F..TERRA;ZZE121..UKP..SED..4FC..TERRA200201-200406

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-YY100×4iCDE120,NDE120,ZZE12#..UKP..TERRA200406

15X6JJ, #,TYPE C:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-02450iZZE120..UKP..TERRA200201-200406

14X5.5JJ, #,TYPE A:REFER TO ILLUSTRATION

main42611-02460iCDE120,ZZE12#..UKP200201-200406

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01007×16iCDE120..UKP..DCR;ZZE121..UKP..RHD..SOL;ZZE121..UKP..WG..4FC..TERRA; ZZE120..UKP;ZZE121..UKP..LHD..SOL;ZZE121..UKP..5F..TERRA;ZZE121..UKP..SED..4FC..TERRA200201-200406

TYPE A:REFER TO ILLUSTRATION

main90942-01033×16iCDE120..UKP..DCR;ZZE121..UKP..RHD..SOL;ZZE121..UKP..WG..4FC..TERRA; ZZE120..UKP;ZZE121..UKP..LHD..SOL;ZZE121..UKP..5F..TERRA;ZZE121..UKP..SED..4FC..TERRA200201-200406

TYPE B:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iCDE120,ZZE12#..UKP200201-200406

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iCDE120,ZZE12#..UKP200201-200406

5 parts on this diagram · 4 diagrams in section
