DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-13130×4iCDE120,ZZE12#200109-200401

15X6JJ, #,TYPE B:REFER TO ILLUSTRATION

main42611-1A480×4iCDE120,ZZE12#200109-200401

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

42601AWHEEL, DISC (FOR SPARE)

main42611-1A480iCDE120,ZZE12#200109-200401

15X6JJ, #,TYPE A:REFER TO ILLUSTRATION

42601CNUT, HUB (FOR AXLE)

main90942-01007×16iCDE120,ZZE12#200109-200401

TYPE A:REFER TO ILLUSTRATION

main90942-01058×16iCDE120,ZZE12#200109-200401

TYPE B:REFER TO ILLUSTRATION

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009×4iCDE120,ZZE12#200109-200401

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iCDE120,ZZE12#200109-200401

42652TIRE

main42652-13100×4iCDE120,ZZE12#..RHD200305-200401

195/60R15

main42652-13110×4iCDE120,ZZE12#..LHD200305-200401

195/60R15

main42652-2B890×4iCDE120,ZZE12#..RHD200109-200305

195/60R15

main42652-2D010×4iCDE120,ZZE12#..LHD200110-200305

195/60R15

42652ATIRE (FOR SPARE)

main42652-13100iCDE120,ZZE12#..RHD200305-200401

195/60R15

main42652-13110iCDE120,ZZE12#..LHD200305-200401

195/60R15

main42652-2B890iCDE120,ZZE12#..RHD200109-200305

195/60R15

main42652-2D010iCDE120,ZZE12#..LHD200110-200305

195/60R15

7 parts on this diagram · 3 diagrams in section
