DISC WHEEL & WHEEL CAP

0001 1 0002 1 0003 1

42601WHEEL, DISC

main42611-10220-03iEP8#,NP80..GL,STD,XL,XLI198912-199601

13X4.5J,TYPE A,SILVER

main42611-12850iEP81..RHD..XLI;EP8#..GL,GLI,S,SI,XL198912-199601

13X5J,ALUMINUM,TYPE C

main42611-16170-03iEP81..3FC..EFI198912-199601

13X5J,TYPE B,SILVER

main42611-16170-03iNP80..STD199201-199405

13X5J,AUSTRIA SPEC,TYPE B,SILVER

main42611-20300-03iEP81..RHD;EP81,NP80..SI,XL198912-199601

13X5J,TYPE B,DARK GRAY

42601AWHEEL, DISC (FOR SPARE)

main42611-10220-03iEP8#,NP80..GL,STD,XL,XLI198912-199601

13X4.5J,TYPE A,SILVER

main42611-12850iEP8#,NP80..LHD..(GL,S,SI,XL,XLI)198912-199601

13X5J,ALUMINUM,TYPE C

main42611-16170-03iEP81..STD198912-199601

13X5J,TYPE B,SILVER

main42611-16170-03iNP80..STD199201-199405

13X5J,AUSTRIA SPEC,TYPE B,SILVER

main42611-20300-03iEP81,NP80..(XL,XLI)..(DSL,EFI)198912-199601

13X5J,TYPE B,DARK GRAY

42601CNUT, HUB (FOR AXLE)

main90942-01007iEP81..S,SI198912-199405

W(HALF CAP)

main90942-01007iEP8#..RHD..XL198912-199601

W(HALF CAP) OR W(FULL CAP)

main90942-01007iEP8#..GL,GLI198912-199405

main90942-01021iEP81,NP80199405-199601

main90942-01033iEP81..RHD..EFI;EP80,NP80..GL,XL;EP81..LHD..(GL,S,SI,XL,XLI)198912-199601

W(ALUMINUM WHEEL)

main90942-01059iEP8#,NP80..S,SI,STD,XL,XLI198912-199405

42611GVALVE (FOR TUBELESS TIRE)

main90942-05004iEP8#,NP80..LHD..(GL,S,SI,XL,XLI)198912-199601

W(ALUMINUM WHEEL)

main90942-05009iEP8#..LHD..(GL,XL)199106-199201

AUSTRIA SPEC OR W(FULL CAP)

main90942-05009iEP81..3FC..EFI198912-199201

W(FULL CAP)

main90942-05009iEP8#,NP80198912-199601

main90942-05009iEP81..SI199201-199601

AUSTRIA SPEC

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05004iEP81..RHD..EFI;EP80,NP80..GL,XL;EP81..LHD..(GL,S,SI,XL,XLI)198912-199601

W(ALUMINUM WHEEL)

main90942-05009iEP81..S,SI;EP81..4F..EFI198912-199201

W(FULL CAP)

main90942-05009iEP80..RHD;EP81..S,SI199106-199201

AUSTRIA SPEC OR W(FULL CAP)

main90942-05009iEP8#,NP80198912-199601

main90942-05009iEP81..SI199201-199601

AUSTRIA SPEC

42652TIRE

main42652-10240iEP8#,NP80..GL,GLI,STD,XL,XLI198912-199601

145SR13

main42652-10270iEP81..4F..EFI;EP81..LHD..(GL,XL)198912-199601

165/70R13 79S

main42652-10270iEP81..4F..EFI;EP81..LHD..(GL,XL)198912-199201

165/70R13 79S,W(ALUMINUM WHEEL)

main42652-12220iEP8#..LHD..(GL,STD,XL)..CBR199007-199601

155SR13

main42652-12220iNP80199201-199601

155SR13,AUSTRIA SPEC

main42652-12382iNP80199306-199601

155SR13 78S,AUSTRIA SPEC

main42652-12382iEP81..LHD..(STD,XLI)199306-199601

155SR13 78S

main42652-16010iEP80..GL,XL;EP81..LHD..(GL,XL)198912-199201

165/70SR13,W(ALUMINUM WHEEL)

main42652-16010iEP81,NP80..(XL,XLI)..(DSL,EFI)198912-199601

165/70SR13

42652ATIRE (FOR SPARE)

main42652-10240iEP8#,NP80..GL,GLI,STD,XL,XLI198912-199601

145SR13

main42652-10270iEP81..S,SI198912-199601

165/70R13 79S

main42652-10270iEP81..5F..XLI;EP80,NP80..LHD..XL198912-199201

165/70R13 79S,ALUMINUM WHEEL

main42652-12220iNP80199201-199601

155SR13,AUSTRIA SPEC

main42652-12220iEP8#..LHD..(GL,STD,XL)..CBR199007-199601

155SR13

main42652-12382iNP80199306-199601

155SR13 78S,AUSTRIA SPEC

main42652-12382iEP81..LHD..(STD,XLI)199306-199601

155SR13 78S

main42652-16010iEP81..5F..XLI;EP80,NP80..LHD..XL198912-199201

165/70SR13,ALUMINUM WHEEL

main42652-16010iEP80..GL,XL;EP81..LHD..(GL,XL)198912-199601

165/70SR13

7 parts on this diagram · 3 diagrams in section
