Toyota YARIS CROSS — SWITCH & RELAY & COMPUTER

0001 1����� & ��������� 0002 1����� & ��������� 0003 1�������� 0004 1�������� 0005 1�������� �������� 0006 1�������� �������� 0007 1��� 0008 1������������ 0009 1������� 0010 1��� & ��� 0011 1��� & ������� 1/3 0012 1��� & ������� 2/3 0013 1��� & ������� 3/3

82715WBRACKET, WIRING HARNESS CLAMP

main82715-K0030iMXPB1#,MXPJ1#¥200202008-202401

main82715-K0030iMXPB1#,MXPJ1#¥200202401

82715XBRACKET, WIRING HARNESS CLAMP, NO.2

main82715-K0080iMXPB15¥670202008-202401

main82715-K0080iMXPB15¥670202401

main8946A-52030iMXPB10,MXPJ1#¥770202008-202401

main8946A-52030iMXPB10,MXPJ1#¥770202401

84540SWITCH ASSY, NEUTRAL START

main84540-K0010iMXPB1#¥7,600202008-202401

89419BSENSOR, SHIFT STROKE

main89419-K2010iMXPB1#¥4,100202401

main89419-K2010iMXPB1#¥4,100202008-202401

89422ASENSOR, WATER TEMPERATURE

main89422-33040iMXPB1#,MXPJ1#¥2,410202008-202401

main89422-33040iMXPB1#,MXPJ1#¥2,410202401

89451ASENSOR, SHIFT LEVER POSITION

main89451-10010iMXPJ1#¥5,900202008-202401

main89451-10010iMXPJ1#¥5,900202401

main89451-42010iMXPB1#¥5,900202401

89467BSENSOR, AIR FUEL RATIO

main89467-52390iMXPB1#¥9,900202401

main89467-K0020iMXPB1#,MXPJ1#¥9,900202008-202401

main89467-K0020iMXPJ1#¥9,900202401

89467CSENSOR, AIR FUEL RATIO, NO.2

main89467-52370iMXPB10,MXPJ1#¥9,900202401

main89467-52380iMXPB15¥9,900202401

main89467-K0030iMXPB10,MXPJ1#¥10,900202008-202401

main89467-K0040iMXPB15¥10,900202008-202401

8946ABRACKET, EXHAUST SENSOR CLAMP

main8946A-52090iMXPB15¥630202008-202401

main8946A-52090iMXPB15¥630202401

89491SENSOR, ENGINE OIL LEVEL

main89491-50081iMXPB1#,MXPJ1#¥3,670202008-202204

sub89491-50082¥3,330

main89491-50082iMXPB1#,MXPJ1#¥3,330202205-202401

main89491-50082iMXPB1#,MXPJ1#¥3,330202401

89535BCOMPUTER, TRANSMISSION CONTROL

main89535-52100iMXPB10¥46,000202008-202401

���U�P�S

main89535-52110iMXPB15¥46,000202008-202401

���U�P�S

89539MBRACKET, TRANSMISSION CONTROL COMPUTER, NO.1

main89539-K0010iMXPB1#¥280202008-202401

89539NBRACKET, TRANSMISSION CONTROL COMPUTER, NO.2

main89539-K0020iMXPB1#¥300202008-202401

89615SENSOR, KNOCK CONTROL

main89615-20090iMXPB1#,MXPJ1#¥2,370202401

main89615-20090iMXPB1#,MXPJ1#¥2,370202008-202401

8271572040BRACKET,WIRING HARNESS CLAMP

main82715-72040¥220

9011906A23

main90119-06A23¥60

9015350015

main90153-50015¥60

9046814044

main90468-14044¥60

9046815007

main90468-15007¥80

9155180835

main91551-80835¥80

9161160618

main91611-60618¥120

9165140620

main91651-40620¥70

9167180612

main91671-80612¥60

9167180616

main91671-80616¥60

24 parts on this diagram · 13 diagrams in section
