Toyota SUPRA — DISC WHEEL & WHEEL CAP

42601WHEEL, DISC

main42611-14580iMA70¥40,400198808-199008

16X7JJ,LH,TYPE A

main42611-14590iMA70¥40,400198808-199008

16X7JJ,RH,TYPE A

main42611-14610-03iMA70..ARL198908-199008

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,3E5 ,4K9

sub42611-14610¥13,900

main42611-14610-03iMA70..C,GEN,V198908-199008

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,3E5

sub42611-14610¥13,900

main42611-14610-03iMA70..EUR,GEN,V198808-198908

16X7JJ,TYPE B,SILVER,043 ,167 ,176 ,206 ,3E5 ,3H4 ,4J7 ,8E3

sub42611-14610¥13,900

main42611-14610-03iMA70..C199008-199108

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,202 ,3E5

sub42611-14610¥13,900

main42611-14610-03iMA70..C199108-199305

16X7JJ,TYPE B,SILVER,050 ,182 ,202 ,3E5 ,3K3 ,6L9 ,749 ,8J3

sub42611-14610¥13,900

main42611-14610-03iMA70..ARL199008-199108

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,202 ,3E5 ,3H8 ,6L9 ,8J3

sub42611-14610¥13,900

main42611-14610-03iMA70..C199008-199108

16X7JJ,TYPE B,SILVER,050 ,176 ,182 ,202 ,3E5 ,3H8 ,8J3

sub42611-14610¥13,900

main42611-14610-03iMA70..EUR,GEN,V198808-198908

16X7JJ,TYPE B,SILVER,043 ,176 ,206 ,3E5 ,8E3

sub42611-14610¥13,900

main42611-14610-03iMA70..GEN,V199108-199305

16X7JJ,TYPE B,SILVER,050 ,182 ,202 ,3E5 ,3K3 ,8J3

sub42611-14610¥13,900

main42611-14610-03iMA70..GEN,V199108-199305

16X7JJ,TYPE B,SILVER,050 ,182 ,202 ,3E5

sub42611-14610¥13,900

main42611-14680iMA70..C,EUR¥37,900198808-198908

16X7JJ,WHITE PACKAGE,LH,TYPE A

sub42611-14681¥40,400

main42611-14681iMA70..C¥40,400198908-199008

16X7JJ,WHITE PACKAGE,LH,TYPE A

main42611-14690iMA70..C,EUR¥37,900198808-198908

16X7JJ,WHITE PACKAGE,RH,TYPE A

sub42611-14691¥40,400

main42611-14691iMA70..C¥40,400198908-199008

16X7JJ,WHITE PACKAGE,RH,TYPE A

main42611-14800iMA70..LHD..(C,V)¥40,400199008-199305

16X7JJ,SILVER,TYPE C

main42611-14810iMA70..TWT..C199008-199305

16X7JJ,WHITE PACKAGE,TYPE C

main42611-14810iMA70..TWT..C199008-199305

16X7JJ,TYPE C

42601AWHEEL, DISC (FOR SPARE)

main42611-14580iMA70..RHD..(C,EUR)¥40,400198808-199008

16X7JJ,LH,TYPE A

main42611-14590iMA70..LHD..(C,EUR)¥40,400198808-199008

16X7JJ,RH,TYPE A

main42611-14600iMA70..C,EUR¥13,900198808-199305

16X7JJ,TYPE A

main42611-14680iMA70..RHD..C¥37,900198808-198908

16X7JJ,LH,TYPE A,WHITE PACKAGE

sub42611-14681¥40,400

main42611-14681iMA70..RHD..C¥40,400198908-199008

16X7JJ,TYPE A,WHITE PACKAGE

main42611-14690iMA70..LHD..(C,EUR)¥37,900198808-198908

16X7JJ,RH,TYPE A,WHITE PACKAGE

sub42611-14691¥40,400

main42611-14691iMA70..LHD..C¥40,400198908-199008

16X7JJ,16X7JJ,TYPE A,WHITE PACKAGE

main42611-14800iMA70..ARL,GEN,V¥40,400199008-199305

16X7JJ,TYPE C

42601CNUT, HUB (FOR AXLE)

main90942-01050iMA70¥760198808-199008

main90942-01062iMA70¥530199008-199305

42601DWEIGHT, BALANCE (FOR DISC WHEEL)

main90942-03146iMA70..TWT..C;MA70..ARL,GEN,V¥200199008-199305

10G

main90942-03146iMA70¥200198808-199008

10G

main90942-03147iMA70..TWT..C;MA70..ARL,GEN,V¥210199008-199305

15G

main90942-03147iMA70¥210198808-199008

15G

main90942-03148iMA70¥210198808-199008

20G

main90942-03148iMA70..TWT..C;MA70..ARL,GEN,V¥210199008-199305

20G

main90942-03149iMA70¥220198808-199008

25G

main90942-03149iMA70..TWT..C;MA70..ARL,GEN,V¥220199008-199305

25G

main90942-03150iMA70..TWT..C;MA70..ARL,GEN,V¥220199008-199305

30G

main90942-03150iMA70¥220198808-199008

30G

main90942-03151iMA70¥230198808-199008

35G

main90942-03151iMA70..TWT..C;MA70..ARL,GEN,V¥230199008-199305

35G

main90942-03152iMA70¥230198808-199008

40G

main90942-03152iMA70..TWT..C;MA70..ARL,GEN,V¥230199008-199305

40G

main90942-03153iMA70..TWT..C;MA70..ARL,GEN,V¥240199008-199305

45G

main90942-03153iMA70¥240198808-199008

45G

main90942-03154iMA70¥240198808-199008

50G

main90942-03154iMA70..TWT..C;MA70..ARL,GEN,V¥240199008-199305

50G

main90942-03155iMA70..TWT..C;MA70..ARL,GEN,V¥440199008-199305

55G

main90942-03155iMA70¥440198808-199008

55G

main90942-03156iMA70¥440198808-199008

60G

main90942-03156iMA70..TWT..C;MA70..ARL,GEN,V¥440199008-199305

60G

main90942-03157iMA70..TWT..C;MA70..ARL,GEN,V¥470199008-199305

65G

main90942-03157iMA70¥470198808-199008

65G

main90942-03158iMA70..TWT..C;MA70..ARL,GEN,V¥470199008-199305

70G

main90942-03158iMA70¥470198808-199008

70G

main90942-03159iMA70..TWT..C;MA70..ARL,GEN,V¥480199008-199305

75G

main90942-03159iMA70¥480198808-199008

75G

main90942-03160iMA70..TWT..C;MA70..ARL,GEN,V¥480199008-199305

80G

main90942-03160iMA70¥480198808-199008

80G

main90942-03167iMA70¥200198808-199008

5G

main90942-03167iMA70..TWT..C;MA70..ARL,GEN,V¥200199008-199305

5G

main90942-03208iMA70..TWT..C;MA70..ARL,GEN,V¥110199008-199305

7.5G,T=6.1

main90942-03208iMA70¥110198908-199008

7.5G,T=6.1

main90942-03209iMA70¥210198908-199008

12.5G,T=7.0

main90942-03209iMA70..TWT..C;MA70..ARL,GEN,V¥210199008-199305

12.5G,T=7.0

main90942-03210iMA70¥210198908-199008

17.5G,T=8.0

main90942-03210iMA70..TWT..C;MA70..ARL,GEN,V¥210199008-199305

17.5G,T=8.0

main90942-03211iMA70..TWT..C;MA70..ARL,GEN,V¥220199008-199305

22.5G,T=8.0

main90942-03211iMA70¥220198908-199008

22.5G,T=8.0

main90942-03212iMA70..TWT..C;MA70..ARL,GEN,V¥220199008-199305

27.5G,T=8.0

main90942-03212iMA70¥220198908-199008

27.5G,T=8.0

main90942-03213iMA70¥230198908-199008

32.5G,T=8.0

main90942-03213iMA70..TWT..C;MA70..ARL,GEN,V¥230199008-199305

32.5G,T=8.0

main90942-03214iMA70¥230198908-199008

37.5G,T=8.0

main90942-03214iMA70..TWT..C;MA70..ARL,GEN,V¥230199008-199305

37.5G,T=8.0

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-14210iMA70¥4,230198808-199008

*ALU

main42603-14260-08iMA70..C,EUR198808-198908

WHITE PACKAGE,WHITE,043

main42603-14261-05iMA70..C198908-199008

WHITE PACKAGE,BEIGE M.,4K9

sub42603-14210¥4,230

main42603-14261-08iMA70..C198908-199008

WHITE PACKAGE,WHITE,050

sub42603-14210¥4,230

main42603-14300-03iMA70..ARL199008-199108

*ALU,SILVER,050 ,176 ,182 ,202 ,3E5 ,3H8 ,6L9 ,8J3

main42603-14300-03iMA70..ARL199008-199108

*ALU,SILVER,050 ,176 ,182 ,202 ,3E5

main42603-14300-03iMA70..ARL199008-199108

*ALU,SILVER,050 ,176 ,182 ,202 ,3E5 ,3H8 ,8J3

main42603-14300-03iMA70..TWT..C199108-199305

*ALU,SILVER,050 ,182 ,202 ,3E5 ,3K3 ,6L9 ,749 ,8J3

main42603-14300-03iMA70..TWT..C199108-199305

*ALU,SILVER,050 ,182 ,202 ,3E5

main42603-14300-03iMA70..TWT..C199108-199305

*ALU,SILVER,050 ,182 ,202 ,3E5 ,3K3 ,8J3

main42603-14310-03iMA70..TWT..C199108-199305

WHITE PACKAGE,DARK GRAY,050 ,182 ,202 ,3E5 ,3K3 ,6L9 ,749 ,8J3

sub42603-14310¥4,620

main42603-14310-03iMA70..TWT..C199008-199108

WHITE PACKAGE,DARK GRAY,050 ,176 ,182 ,202 ,3E5 ,3H8 ,6L9 ,8J3

sub42603-14310¥4,620

main42603-14310-08iMA70..TWT..C199008-199305

WHITE PACKAGE,SUPER WHITE,050

sub42603-14310¥4,620

42611GVALVE (FOR TUBELESS TIRE)

main90942-05004iMA70..TWT..C;MA70..ARL,GEN,V¥620199008-199305

main90942-05004iMA70..C,EUR¥620198808-198908

main90942-05004iMA70¥620198808-199008

main90942-05009iMA70..C,EUR¥390198808-199305

FOR SPARE TIRE

42652TIRE

main42652-14530iMA70..V198808-199008

225/50R16

main42652-14550iMA70..ARL,GEN198812-199008

225/50VR16

main42652-14550iMA70..GEN198808-198812

225/50VR16

main42652-14680iMA70..TWT..C199008-199305

225/50ZR16

main42652-14760iMA70..V199008-199305

225/50R16 92V M.

42652ATIRE (FOR SPARE)

main42652-14530iMA70..V198808-199008

225/50R16

main42652-14550iMA70..ARL,GEN198812-199008

225/50VR16

main42652-14550iMA70..GEN198808-198812

225/50VR16

main42652-14570iMA70..C,EUR198808-199305

205/55R16

main42652-14700iMA70..GEN199008-199305

225/50R16 92V

main42652-14760iMA70..V199008-199305

225/50R16 92V M.

8 parts on this diagram · 1 diagram in section
