Toyota STARLET — REAR SPRING & SHOCK ABSORBER

4102

42110FBEAM ASSY, REAR AXLE

48231ASPRING, COIL, REAR RH

48231BSPRING, COIL, REAR LH

48257CINSULATOR, REAR COIL SPRING, UPPER RH

48258BINSULATOR, REAR COIL SPRING, LOWER RH

48258CINSULATOR, REAR COIL SPRING, LOWER LH

48259AINSULATOR, REAR COIL SPRING, UPPER LH

48530ABSORBER ASSY, SHOCK, REAR RH

main48530-WC019

main48530-WC020

48540ABSORBER ASSY, SHOCK, REAR LH

main48530-WC019

main48530-WC020

48553DCAP, REAR SHOCK ABSORBER, RH

48554ACAP, REAR SHOCK ABSORBER, LH

90118WC491

main90118-WC491

90118WC531

main90118-WC531

14 parts on this diagram · 1 diagram in section
