Toyota STARLET — FRONT FENDER APRON & DASH PANEL

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1 0007 1

5302

5303

53202DCUSHION, RADIATOR SUPPORT

53205SUPPORT SUB-ASSY, RADIATOR, UPPER

main53205-WC001

main53205-WC002

5503

55744CMEMBER, FRONT PANEL, UPPER

57104AMEMBER SUB-ASSY, FRONT CROSS

90118WC015

main90118-WC015

90118WC022

main90118-WC022

90118WC051

main90118-WC051

90118WC222

main90118-WC222

90118WC570

main90118-WC570

12 parts on this diagram · 7 diagrams in section
