Toyota PIXIS VAN — FRONT DOOR WINDOW REGULATOR & HINGE

68710HINGE ASSY, FRONT DOOR, UPPER RH

main68710-B1030iS700,710¥1,790202112

68720HINGE ASSY, FRONT DOOR, UPPER LH

main68720-B1030iS700,710¥1,790202112

68730HINGE ASSY, FRONT DOOR, LOWER RH

main68730-B5040iS700,710¥1,730202112

68740HINGE ASSY, FRONT DOOR, LOWER LH

main68740-B5020iS700,710¥1,730202112

69810AREGULATOR ASSY, FRONT DOOR WINDOW, RH

main69810-B5040iS700,710¥17,900202112

69820REGULATOR ASSY, FRONT DOOR WINDOW, LH

main69820-B5100iS700,710¥17,900202112

8202

9004105264

main90041-05264¥150

9004105575

main90041-05575¥170

9004119A49

main90041-19A49¥110

9167180612

main91671-80612¥60

11 parts on this diagram · 1 diagram in section
