Toyota GLANZA — BACK DOOR LOCK & HANDLE

0001 1 0002 1

6708

68810CHINGE ASSY, BACK DOOR, RH

68820CHINGE ASSY, BACK DOOR, LH

68950CSTAY ASSY, BACK DOOR, RH

68960BSTAY ASSY, BACK DOOR, LH

68961BOLT, BACK DOOR STAY

main68961-WC003

69351BHOLDER, BACK DOOR SWITCH

7601

68838WC001PAD, BACK DOOR HINGE, NO.1

main68838-WC001

90118WC086

main90118-WC086

90118WC106

main90118-WC106

11 parts on this diagram · 2 diagrams in section
