Toyota CROWN — REAR DISC BRAKE CALIPER & DUST COVER
47713RPLUG, BLEEDER(FOR REAR DISC BRAKE)
47714RCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)
47810CALIPER ASSY, DISC BRAKE, REAR RH
sub47730-30040
47810ABOLT, HEXAGON(FOR REAR CALIPER)
L=15.5
L=16.4
47810KCYLINDER KIT, DISC BRAKE, REAR
sub04479-30041
47810NSEAL KIT, DISC BRAKE, REAR
47820CALIPER ASSY, DISC BRAKE, REAR LH
sub47750-30040
47831PISTON, REAR DISC BRAKE
47831ARING, SET(FOR REAR DISC BRAKE PISTON)
47844SHIM, ANTISQUEAL, NO.1(FOR REAR DISC BRAKE)
47845SHIM, ANTISQUEAL, NO.2(FOR REAR DISC BRAKE)
47846APIN, W/HOLE(FOR REAR DISC BRAKE PAD)
47848SPRING, ANTI-RATTLE, NO.1(FOR REAR DISC BRAKE)
47849SPRING, ANTI-RATTLE, NO.2(FOR REAR DISC BRAKE)
47866CAP, TORQUE PLATE PIN, REAR
47866APLUG, HOLE(FOR TORQUE PLATE PIN REAR CAP)
47868PROTECTOR, DISC BRAKE PAD, REAR RH
47869PROTECTOR, DISC BRAKE PAD, REAR LH
47870WIRE ASSY,PAD WEAR INDICATOR, REAR RH
47890WIRE ASSY, PAD WEAR INDICATOR, REAR LH
9010110481
9010910001
main90109-10001
9017906158
9111240608
9111240612
main91112-40612
9411040600
9453100600
9453101000
29 parts on this diagram · 3 diagrams in section
