Toyota CROWN — FRONT AXLE HUB

0001 1 0002 1

42611BBOLT, HUB (FOR FRONT AXLE)

main90942-02021iMS8#,95,RS80¥390197410-197703

12-1.5PX38-24

sub90942-02035¥240

main90942-02036iMS8#,95,RS80¥250197703-197908

12-1.5PX33-20.5 FOR DISC BRAKE

sub90942-02048¥460

main90942-02037iRS80..GEN¥240197703-197908

12-1.5PX40-27.5 FOR DRUM BRAKE

sub90942-02049¥240

43442CAP, KNUCKLE GREASE RETAINER, INNER

main43442-30031iRS80¥340197410-197908

43445GASKET, KNUCKLE GREASE RETAINER CAP

main43445-30021iRS80¥240197410-197908

43501DRUM SUB-ASSY, FRONT BRAKE

main43512-30060iRS80¥15,100197410-197908

43501APIECE, BALANCE (FOR FRONT BRAKE DRUM)

main90937-01100iRS80¥140197410-197908

40.5G,40.5G.

main90937-01117iRS80¥130197410-197908

10G,10G.

main90937-01118iRS80¥130197410-197908

20G,20G.

main90937-01119iRS80..GEN¥130197410-197908

30G,30G.

main90937-01146iRS80¥250197410-197908

25G,50G.

main90937-01178iRS80..GEN¥240197410-197908

56G,56G.

main90937-01179iRS80197410-197908

66G,66G.

main90937-01180iRS80197410-197908

76G,76G.

main90937-01181iRS80..GEN197410-197908

86G,86G.

main90937-01182iRS80..GEN197410-197908

96G,96G.

43501BBOLT, SET (FOR FRONT BRAKE DRUM SETTING)

main90113-10007iRS80¥110197410-197908

43510HUB AND BRAKE DRUM ASSY, FRONT AXLE, RH

main43510-30120iRS80¥26,600197410-197908

43510ASEAL, OIL (FOR FRONT AXLE HUB)

main90311-48122iMS8#,95,RS80¥420197410-197908

sub90311-48001¥490

43510BBEARING, TAPERED ROLLER (FOR FRONT AXLE INNER BEARING)

main90368-34083iMS8#,95,RS80¥2,400197410-197908

43510CBEARING, TAPERED ROLLER (FOR FRONT AXLE OUTER BEARING)

main90368-21082iMS8#,95,RS80¥2,050197410-197908

43510DWASHER, CLAW (FOR STEERING KNUCKLE WASHER)

main90214-20005iMS8#,95,RS80¥190197410-197908

43510ENUT (FOR STEERING KNUCKLE)

main90170-19185iMS8#,95,RS80¥300197611-197908

main90171-19037iMS8#,95,RS80¥310197410-197611

43511HUB, FRONT AXLE

main43502-30010iRS80..GEN¥13,200197602-197908

FOR DRUM BRAKE

main43511-30904iMS8#,95,RS80¥14,300197410-197908

FOR DISC BRAKE

43514CAP, FRONT HUB GREASE

main43514-22020iMS8#,95,RS80¥450197410-197908

43520HUB AND BRAKE DRUM ASSY, FRONT AXLE, LH

main43510-30120iRS80¥26,600197410-197908

43525CAP, FRONT WHEEL ADJUSTING LOCK

main43525-22010iMS8#,95,RS80¥240197611-197908

9538104025

main95381-04025¥130

9538104030

main95381-04030¥50

18 parts on this diagram · 2 diagrams in section
