Toyota COROLLA CROSS — FRONT FENDER APRON & DASH PANEL

0001 1�������&��������������� 0002 1�����������&���������� 0003 1���������

16561CSEAL, RADIATOR TO SUPPORT, NO.1

main16561-24010iM20AFKS,2ZRFXE..MXGA10,ZVG1#¥6,100202310

main16561-37150i2ZR#..ZSG10,ZVG1#¥7,900202108-202310

16592AGUIDE, RADIATOR AIR, NO.3

main16592-37100iM20AFKS,2ZRFXE..MXGA10,ZVG1#¥3,850202310

main16592-37100i2ZR#..ZSG10,ZVG1#¥3,850202108-202310

16594AGUIDE, RADIATOR AIR, NO.2

main16594-24040iM20AFKS,2ZRFXE..MXGA10,ZVG1#¥2,400202310

main16594-37010i2ZRFXE..ZVG1#¥2,010202108-202310

main16594-37040i2ZRFAE..ZSG10¥1,590202108-202310

8718

9018906237

main90189-06237¥100

9046707214

main90467-07214¥70

6 parts on this diagram · 3 diagrams in section
