Toyota C-HR — CAUTION PLATE (EXTERIOR & INTERIOR)
11285ALABEL, COOLANT SYSTEM NOTICE
TYPE B:REFER ILLUST.
TYPE C:REFER ILLUST.
TYPE A:REFER ILLUST.
TYPE A:REFER ILLUST.
TYPE A:REFER ILLUST.
11291BPLATE, ENGINE NAME
11293DLABEL, ENGINE CAUTION
16793BLABEL, COOLING FAN INFORMATION
47997CLABEL, ACCUMULATOR CAUTION, NO.1
(J)
(L)
88723HLABEL, COOLER SERVICE CAUTION
EUROPE REFRIGERANT CORRESPONDENCE-WITHOUT&LIGHT GRADE
LIGHT GRADE
EUROPE REFRIGERANT CORRESPONDENCE-WITHOUT
G9275LABEL, BATTERY CAUTION, NO.1
(L)
(J)
8 parts on this diagram · 4 diagrams in section
