Toyota C-HR (JPP) — REAR DISC BRAKE CALIPER & DUST COVER

0001 1 0002 1 0003 1

04466PAD KIT, DISC BRAKE, REAR

main04466-10010iZGX10¥6,100201801-201806

MARK AK NS554

main04466-42080iZGX10¥6,100201910-202212

MARK NBK 478-XA5

main04466-F4010iZGX10¥6,300201806-201910

MARK NBK D6360

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-10091iZGX10¥3,200201801-201806

main04479-42100iZGX10¥2,200201910-202212

main04479-F4010iZGX10201806-201910

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-33090iZGX10¥1,550201910-202212

main04946-48130iZGX10¥1,780201801-201806

main04946-F4010iZGX10201806-201910

04948FITTING KIT, DISC BRAKE, REAR

main04948-12071iZGX10¥1,730202204-202212

main04948-33060iZGX10¥1,730201910-202204

main04948-58010iZGX10¥1,040201801-201806

main04948-F4010iZGX10201806-201910

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010iZGX10¥160201801-201806

main31478-30010iZGX10¥160201910-202212

main90069-39027iZGX10201806-201910

4601

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-20010iZGX10¥200201801-201806

main47547-20010iZGX10¥200201910-202212

main47547-F4030iZGX10201806-201910

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90015-AA603iZGX10¥270201801-201806

*8-1.00PX23-12.5

sub90016-AA614¥270

main90015-AA603iZGX10¥270201910-202212

*8-1.00PX23-12.5

sub90016-AA614¥270

main90069-31417iZGX10201806-201910

*8-1.00PX22-10

47775DBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47875-33270iZGX10¥70201910-202212

main47875-33270iZGX10¥70201801-201806

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-33010iZGX10¥1,240201910-202212

main47803-33010iZGX10¥1,240201801-201806

main47881-F4030iZGX10201806-201910

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-33010iZGX10¥1,240201801-201806

main47804-33010iZGX10¥1,240201910-202212

main47882-F4030iZGX10201806-201910

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-12174iZGX10¥130201801-201910

main90105-12174iZGX10¥130201910-202212

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-78010iZGX10¥510201801-201806

main47814-78010iZGX10¥510201910-202212

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-78010iZGX10¥510201801-201806

main47815-78010iZGX10¥510201910-202212

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-10030iZGX10¥4,380201801-201806

main47821-10030iZGX10¥4,380201910-202212

main47821-F9010iZGX10201806-201910

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47822-10030iZGX10¥4,380201801-201806

main47822-10030iZGX10¥4,380201910-202212

main47822-F9010iZGX10201806-201910

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-10030iZGX10¥28,800201801-201806

main47830-42090iZGX10¥26,100201910-202212

main47830-F4030iZGX10201806-201910

47831PISTON, REAR DISC BRAKE

main47831-10030iZGX10¥800201801-201806

main47831-48130iZGX10¥920201910-202212

main47831-F4030iZGX10201806-201910

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-10030iZGX10¥28,800201801-201806

main47850-42080iZGX10¥26,100201910-202212

main47850-F4030iZGX10201806-201910

47879RBUSH, CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47769-50010iZGX10¥50201910-202212

main47769-50010iZGX10¥50201801-201806

20 parts on this diagram · 3 diagrams in section
