Toyota BZ4X — CAUTION PLATE (EXTERIOR & INTERIOR)

0001 1ENGINE ROOM & EXTERIOR 0002 1INTERIOR

11285KLABEL, COOLANT SYSTEM INFORMATION

main11285-10040iEM..XEAM10,YEAM15¥110202203-202411

16793ELABEL, COOLING FAN CAUTION

main16793-36030iEM..XEAM10,YEAM15¥110202203-202411

288A2LABEL, BATTERY LOCATION

main288A2-10010iEM..XEAM10,YEAM15¥110202203-202411

42661LABEL, TIRE PRESSURE INFORMATION

main42661-42D70iXEAM10,YEAM15..E,L,M¥120202203-202207

sub42661-42D71¥110

main42661-42D71iXEAM10,YEAM15..E,L,M¥110202208-202411

main42661-42D80iXEAM10,YEAM15..H¥120202203-202207

TEC. PACKAGE

sub42661-42D81¥110

main42661-42D81iYEAM15..M..CND¥110202208-202411

TEC. PACKAGE

main42661-42D81iXEAM10,YEAM15..H¥110202412

NIGHT SHADE PACKAGE

74511FLABEL, NAME (IDENTIFICATION LASER LABEL)

88723ELABEL, COOLER SERVICE CAUTION

main88723-42160iXEAM10,YEAM15202203-202411

G9131LABEL, ELECTRIC VEHICLE EMISSION CONTROL INFORMATION

mainG913142020iXEAM10202203-202307

mainG913142030iYEAM15202203-202311

mainG913142040iYEAM15202311-202411

mainG913142050iXEAM10202307-202411

mainG913142080iXEAM10202412

mainG913142090iYEAM15202412

7 parts on this diagram · 2 diagrams in section
