Toyota AVALON — DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
15X6JJ,TYPE B:REFER TO ILLUSTRATION
15X6JJ,TYPE A:REFER TO ILLUSTRATION
42601AWHEEL, DISC (FOR SPARE)
15X6JJ,TYPE B:REFER TO ILLUSTRATION
15X6JJ,TYPE A:REFER TO ILLUSTRATION
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER TO ILLUSTRATION
15 INCHES DISC WHEEL
42611GVALVE (FOR TUBELESS TIRE)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
42611JVALVE (FOR TUBELESS TIRE SPARE)
TYPE A:REFER TO ILLUSTRATION
TYPE B:REFER TO ILLUSTRATION
5 parts on this diagram · 4 diagrams in section
