SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE & TRANSMISSION 0003 1ENGINE & TRANSMISSION 0004 1ENGINE ROOM 0005 1ENGINE ROOM 0006 1ENGINE ROOM RELAY BLOCK 0007 1ENGINE ROOM RELAY BLOCK 0008 1COWL 0009 1COWL 0010 1INSTRUMENT PANEL 1/2 0011 1INSTRUMENT PANEL 1/2 0012 1INSTRUMENT PANEL 1/2 0013 1INSTRUMENT PANEL 2/2 0014 1INSTRUMENT PANEL 2/2 0015 1STEERING 0016 1STEERING 0017 1STEERING 0018 1SEAT 0019 1DOOR & ROOF & FLOOR 1/2 0020 1DOOR & ROOF & FLOOR 1/2 0021 1DOOR & ROOF & FLOOR 2/2

83520GAGE ASSY,OIL PRESSURE SENDER

main83520-60050iUCK6#200711-201507

sub83520-60051

main83520-60051iUSK6#201508-201709

84540SWITCH ASSY, NEUTRAL START

main84540-0C010iUCK6#,UPK6#,USK6#200711-201708

89465SENSOR, OXYGEN

main89465-0C180iUSK65..HTWCF200711-201508

LH

main89465-0C190iUSK65..HTWCF200711-201508

RH

main89465-0C250iUSK6#201708

LH

main89465-0C260iUSK6#201708

RH

main89465-0C290iUSK6#..HTWC201411-201708

LH

main89465-0C300iUSK6#..HTWC201411-201708

RH

main89465-34160iUSK6#..HTWC201308-201410

LH

main89465-34170iUSK6#..HTWC201308-201410

RH

89467BSENSOR, AIR FUEL RATIO

main89467-04060iUPK6#200711-201208

main89467-04060iUSK6#200711-200906

RH & LH

main89467-04060iUSK6#200906-201106

LH

main89467-04090iUSK65..HTWCF201203-201508

LH

main89467-0C030iUSK6#200906-201106

RH

main89467-0C050iUSK65..HTWCF201203-201508

RH

main89467-0C060iUSK6#201308-201708

LH

main89467-0C070iUSK6#..HTWC201308-201708

RH

main89467-22030iUSK6#201106-201203

RH

main89467-34030iUSK6#201106-201203

LH

89615SENSOR, KNOCK CONTROL

main89615-06010iUSK65..HTWCF201008-201709

(L)

main89615-20090iUSK6#201008-201709

(J)

main89615-20090iUPK6#,USK6#200711-201008

827150C270BRACKET,WIRING HARNESS CLAMP

main82715-0C270

827150C290BRACKET,WIRING HARNESS CLAMP

main82715-0C290

9008011211

main90080-11211

9008017242

main90080-17242

90119A0057

main90119-A0057

9165140830

main91651-40830

11 parts on this diagram · 21 diagrams in section
