BATTERY & BATTERY CABLE

0001 1 0002 1

28800BATTERY

main28800-50060i2UZFE..UZJ100199801-199803

80D26L

main28800-66021i2UZFE..UZJ100199801-200708

105D31L

sub28800-66022

main28800-74142i2UZFE..UZJ100199803-199907

80D26L

sub28800-64132

28800ATERMINAL, BATTERY POSITIVE

main82675-60020i2UZFE..UZJ100200208-200505

main90982-05035i2UZFE..UZJ100199801-200208

28800DCOVER, CONNECTOR(FOR BATTERY TERMINAL)

main82821-60040i2UZFE..UZJ100199801-199907

main82821-60041i2UZFE..UZJ100199907-200208

28897PLATE, BATTERY CAUTION

main28897-46020i2UZFE..UZJ100199801-200505

CANADA SPEC

main28898-20010i2UZFE..UZJ100199801-200505

9017908053

main90179-08053

5 parts on this diagram · 2 diagrams in section
