SEAT & SEAT TRACK

0001 1FRONT SEAT 0002 1FRONT SEAT 0003 1FRONT SEAT 0004 1FRONT SEAT (ADJUSTER) 0005 1REAR NO.1 SEAT (TYPE B) 0006 1REAR NO.1 SEAT (TYPE B) 0007 1REAR NO.1 SEAT (TYPE A) 0008 1REAR NO.1 SEAT (TYPE A) 0009 1REAR NO.1 SEAT (ADJUSTER) (TY0010 1REAR NO.1 SEAT (ADJUSTER) (TY0011 1REAR NO.1 SEAT (HINGE & STRIK0012 1REAR NO.2 SEAT 0013 1REAR NO.2 SEAT 0014 1REAR NO.2 SEAT (FITTING PARTS0015 1REAR NO.2 SEAT (STRIKER)

71071SCOVER, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

main71071-6A060-B0iUZJ100199801-200208

GRAY,TRIM1#

main71071-6A060-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71071-6A070-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71071-6A070

main71071-6A070-A1iUZJ100200208-200601

IVORY,TRIM0#

sub71071-6A070

main71071-6A070-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub71071-6A070

main71071-6A070-B1iUZJ100200208-200601

STONE,TRIM1#

sub71071-6A070

71072SCOVER, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

main71072-60700-B0iUZJ100199801-200208

GRAY,TRIM1#

main71072-60700-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71072-60710-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71072-60710

main71072-60710-A1iUZJ100200208-200708

IVORY,TRIM0#

sub71072-60710

main71072-60710-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub71072-60710

main71072-60710-B1iUZJ100200208-200708

STONE,TRIM1#

sub71072-60710

71073SCOVER, FRONT SEATBACK, RH(FOR SEPARATE TYPE)

main71073-60860-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71073-60860

main71073-60860-A1iUZJ100200208-200708

IVORY,TRIM0#

sub71073-60860

main71073-60860-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub71073-60860

main71073-60860-B1iUZJ100200208-200708

STONE,TRIM1#

sub71073-60860

main71073-6A070-B0iUZJ100199801-200208

GRAY,TRIM1#

main71073-6A070-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71073-6A360-A0iUZJ100200208-200708

W(*80,SIDE),IVORY,TRIM0#

main71073-6A360-B0iUZJ100200208-200708

W(*80,SIDE),STONE,TRIM1#

71074SCOVER, FRONT SEATBACK, LH(FOR SEPARATE TYPE)

main71074-60710-B0iUZJ100199801-200208

GRAY,TRIM1#

main71074-60710-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71074-60720-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71074-60720

main71074-60720-A1iUZJ100200208-200708

IVORY,TRIM0#

sub71074-60720

main71074-60720-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub71074-60720

main71074-60720-B1iUZJ100200208-200708

STONE,TRIM1#

sub71074-60720

main71074-60870-A0iUZJ100200208-200708

W(*80,SIDE),IVORY,TRIM0#

main71074-60870-B0iUZJ100200208-200708

W(*80,SIDE),STONE,TRIM1#

71410SCUSHION ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

main71410-6A410-B0iUZJ100199801-200208

SHADOW GRAY,TRIM1#

main71410-6A410-E1iUZJ100199801-200208

OAK,TRIM4#

main71410-6A470-B0iUZJ100199801-200208

W(LEATHER SEAT),SHADOW GRAY,TRIM1#

main71410-6A470-E0iUZJ100199801-200208

W(LEATHER SEAT),OAK,TRIM4#

71420SCUSHION ASSY, FRONT SEAT, LH (FOR SEPARATE TYPE)

main71420-6A300-B0iUZJ100199801-200208

SHADOW GRAY,TRIM1#

main71420-6A300-E1iUZJ100199801-200208

OAK,TRIM4#

main71420-6A320-B0iUZJ100199801-200208

W(LEATHER SEAT),SHADOW GRAY,TRIM1#

main71420-6A320-E0iUZJ100199801-200208

W(LEATHER SEAT),OAK,TRIM4#

71430SBACK ASSY, FRONT SEAT, RH(FOR SEPARATE TYPE)

main71040-60070-B0iUZJ100199801-200208

W(LEATHER SEAT),SHADOW GRAY,TRIM1#

main71040-60070-E0iUZJ100199801-200208

W(LEATHER SEAT),OAK,TRIM4#

main71040-60230-B0iUZJ100199801-200208

SHADOW GRAY,TRIM1#

main71040-60230-E1iUZJ100199801-200208

OAK,TRIM4#

main71430-60A20-A0iUZJ100200401-200708

W(*80,SIDE),IVORY,TRIM0#

main71430-60A20-B0iUZJ100200401-200708

W(*80,SIDE),STONE,TRIM1#

main71430-6A390-A0iUZJ100200208-200308

W(*80,SIDE),IVORY,TRIM0#

main71430-6A390-B0iUZJ100200208-200308

W(*80,SIDE),STONE,TRIM1#

main71430-6A530-A0iUZJ100200308-200401

W(*80,SIDE),IVORY,TRIM0#

sub71430-60A20

main71430-6A530-B0iUZJ100200308-200401

W(*80,SIDE),STONE,TRIM1#

sub71430-60A20

71440SBACK ASSY, FRONT SEAT, LH(FOR SEPARATE TYPE)

main71070-60060-B0iUZJ100199801-200208

SHADOW GRAY,TRIM1#

main71070-60060-E1iUZJ100199801-200208

OAK,TRIM4#

main71070-60090-B0iUZJ100199801-200208

W(LEATHER SEAT),SHADOW GRAY,TRIM1#

main71070-60090-E0iUZJ100199801-200208

W(LEATHER SEAT),OAK,TRIM4#

main71440-60A10-A0iUZJ100200401-200708

W(*80,SIDE),IVORY,TRIM0#

main71440-60A10-B0iUZJ100200401-200708

W(*80,SIDE),STONE,TRIM1#

main71440-6A200-A0iUZJ100200208-200401

W(*80,SIDE),IVORY,TRIM0#

sub71440-60A10

main71440-6A200-B0iUZJ100200208-200401

W(*80,SIDE),STONE,TRIM1#

sub71440-60A10

71511SPAD, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

main71501-60070iUZJ100199801-200208

W(LEATHER SEAT)

main71501-60070iUZJ100200208-200601

main71501-60110iUZJ100199801-200208

71512SPAD, FRONT SEAT CUSHION, LH (FOR SEPARATE TYPE)

main71502-60090iUZJ100199801-200208

W(LEATHER SEAT)

main71502-60090iUZJ100200208-200505

main71512-60120iUZJ100199801-200208

71517CLOTH, FRONT SEAT CUSHION UNDER

main71517-60170iUZJ100199801-199903

main71517-60200iUZJ100199903-200208

71551SPAD, FRONT SEATBACK, RH(FOR SEPARATE TYPE)

main71551-60230iUZJ100199801-200208

W(LEATHER SEAT)

main71551-60230iUZJ100200208-200505

main71551-60280iUZJ100199801-200208

71552SPAD, FRONT SEATBACK, LH(FOR SEPARATE TYPE)

main71552-60150iUZJ100199801-200208

main71552-60170iUZJ100200208-200505

main71552-60170iUZJ100199801-200208

W(LEATHER SEAT)

71571PAD, FRONT SEATBACK SILENCER, A

main71571-60020iUZJ100199801-200308

71610SSPRING ASSY, FRONT SEAT CUSHION, RH(FOR SEPARATE TYPE)

main71610-60230iUZJ100199801-200601

main71610-60330iUZJ100200601

71620SSPRING ASSY, FRONT SEAT CUSHION, LH(FOR SEPARATE TYPE)

main71620-60230iUZJ100199801-200505

71630SSPRING ASSY, FRONT SEATBACK, RH(FOR SEPARATE TYPE)

main71630-60160iUZJ100199801-200308

main71630-60240iUZJ100200308-200505

71640SSPRING ASSY, FRONT SEATBACK, LH(FOR SEPARATE TYPE)

main71640-60100iUZJ100199801-200505

71705BOARD SUB-ASSY, FRONT SEATBACK, RH

main71705-60180-B0iUZJ100199801-200208

GRAY,TRIM1#

main71705-60180-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71705-60190-A1iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71705-60230

main71705-60190-B1iUZJ100199801-200208

W(LEATHER SEAT),MD.GRAY,TRIM1#

sub71705-60230

main71705-60230-A0iUZJ100200208-200708

IVORY,TRIM0#

main71705-60230-B0iUZJ100200208-200708

STONE,TRIM1#

71706BOARD SUB-ASSY, FRONT SEATBACK, LH

main71705-60180-B0iUZJ100199801-200208

GRAY,TRIM1#

main71705-60180-E0iUZJ100199801-200208

LT. OAK,TRIM4#

main71705-60190-A1iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71705-60230

main71705-60190-B1iUZJ100199801-200208

W(LEATHER SEAT),MD.GRAY,TRIM1#

sub71705-60230

main71705-60230-A0iUZJ100200208-200708

IVORY,TRIM0#

main71705-60230-B0iUZJ100200208-200708

STONE,TRIM1#

71706BCLIP, FRONT SEATBACK BOARD

main71769-60020iUZJ100199801-200505

71789BPOCKET, FRONT SEATBACK BOARD

main71780-60020-A1iUZJ100200208-200708

IVORY,TRIM0#

sub71780-60020

main71780-60020-B0iUZJ100199801-200208

GRAY,TRIM1#

sub71780-60020

main71780-60020-B2iUZJ100200208-200708

STONE,TRIM1#

sub71780-60020

main71780-60020-E0iUZJ100199801-200208

LT. OAK,TRIM40,41

sub71780-60020

71910AHEADREST ASSY, FRONT SEAT

main71910-60420-B0iUZJ100199801-200208

GRAY,TRIM1#

sub71910-60420

main71910-60420-E0iUZJ100199801-200208

OAK,TRIM4#

sub71910-60420

main71910-60440-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub71910-60440

main71910-60440-A1iUZJ100200208-200708

IVORY,TRIM0#

sub71910-60440

main71910-60440-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub71910-60440

main71910-60440-B1iUZJ100200208-200708

STONE,TRIM1#

sub71910-60440

71931SUPPORT, FRONT SEAT HEADREST

main71930-28040-A0iUZJ100199801-200103

W(LOCK),IVORY,TRIM40,41

sub71930-60030

sub71930-28040

main71930-28040-B5iUZJ100199801-200103

W(LOCK),MD.GRAY,TRIM1#

sub71930-60030

sub71930-28040

main71930-60030-A0iUZJ100200103-200208

W(LOCK),IVORY,TRIM41

sub71930-60030

main71930-60030-A1iUZJ100200208-200708

W(LOCK),IVORY,TRIM0#

sub71930-60030

main71930-60030-B0iUZJ100200103-200208

W(LOCK),MD.GRAY,TRIM1#,40

sub71930-60030

main71930-60030-B1iUZJ100200208-200708

W(LOCK),STONE,TRIM1#

sub71930-60030

main71931-28050-A0iUZJ100199801-200103

W/O(LOCK),IVORY,TRIM40,41

sub71931-28050

main71931-28050-B5iUZJ100199801-200103

W/O(LOCK),MD.GRAY,TRIM1#

sub71931-28050

main71931-60020-A0iUZJ100200103-200208

W/O(LOCK),IVORY,TRIM41

sub71931-60020

main71931-60020-A1iUZJ100200208-200708

W/O(LOCK),IVORY,TRIM0#

sub71931-60020

main71931-60020-B0iUZJ100200103-200208

W/O(LOCK),MD.GRAY,TRIM1#,40

sub71931-60020

main71931-60020-B1iUZJ100200208-200708

W/O(LOCK),STONE,TRIM1#

sub71931-60020

72760DADJUSTER ASSY, LUMBAR SUPPORT, LH

main72750-60060iUZJ100200401-200505

main72750-60070iUZJ100199801-200312

72797SPACER, LUMBAR SUPPORT

main72797-50010iUZJ100199801-200505

72848ACAP, SEAT ARMREST, NO.1

main72848-60010-A0iUZJ100199801-200208

IVORY,TRIM40

sub72848-60010

main72848-60010-A1iUZJ100200208-200708

IVORY,TRIM0#

sub72848-60010

main72848-60010-B0iUZJ100199801-200208

MD.GRAY,TRIM1#

sub72848-60010

main72848-60010-B1iUZJ100200208-200708

STONE,TRIM1#

sub72848-60010

main72848-60010-E0iUZJ100199801-200208

OAK,TRIM41

sub72848-60010

72880ARMREST ASSY, SEAT, C RH

main72880-60010-B0iUZJ100199801-200208

GRAY,TRIM1#

main72880-60010-E0iUZJ100199801-200208

OAK,TRIM4#

main72880-60020-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub72880-60031

main72880-60020-A1iUZJ100200208-200708

IVORY,TRIM0#

sub72880-60031

main72880-60020-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub72880-60031

main72880-60020-B1iUZJ100200208-200708

STONE,TRIM1#

sub72880-60031

72890ARMREST ASSY, SEAT, C LH

main72890-60010-B0iUZJ100199801-200208

GRAY,TRIM1#

main72890-60010-E0iUZJ100199801-200208

OAK,TRIM4#

main72890-60020-A0iUZJ100199801-200208

W(LEATHER SEAT),IVORY,TRIM4#

sub72890-60031

main72890-60020-A1iUZJ100200208-200708

IVORY,TRIM0#

sub72890-60031

main72890-60020-B0iUZJ100199801-200208

W(LEATHER SEAT),GRAY,TRIM1#

sub72890-60031

main72890-60020-B1iUZJ100200208-200708

STONE,TRIM1#

sub72890-60031

9018305016

main90183-05016

9038635001

main90386-35001

9151281070

main91512-81070

9165160614

main91651-60614

33 parts on this diagram · 15 diagrams in section
