DISC WHEEL & WHEEL CAP
42601AWHEEL, DISC (FOR SPARE)
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER ILLUST.
42601FWHEEL, DISC (FOR FRONT)
42601RWHEEL, DISC (FOR REAR)
42603AORNAMENT SUB-ASSY, WHEEL HUB(FOR FRONT)
*ALU,TYPE A:REFER ILLUST.
*ALU,TYPE A:REFER ILLUST.
42603BORNAMENT SUB-ASSY, WHEEL HUB(FOR REAR)
*ALU,TYPE A:REFER ILLUST.
*ALU,TYPE A:REFER ILLUST.
42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR
42607AVALVE SUB-ASSY, TIRE PRESSURE MONITOR (FOR SPARE)
42611GVALVE (FOR TUBELESS TIRE)
42611JVALVE (FOR TUBELESS TIRE SPARE)
42652TIRE
265/65R17,*D/L,SPORT PACKAGE&REAR SUSPENSION-W(AIR SUSPENSION & KINETIC SUSPENSION)
265/65R17,*D/L
265/65R17,*D/L,CANADA GX
265/65R17,MICHELIN
P265/65R17,B/S
P265/65R17,B/S
P265/65R17,B/S,CANADA GX
42652ATIRE (FOR SPARE)
265/65R17,*D/L
265/65R17,*D/L,CANADA GX
265/65R17,MICHELIN
P265/65R17,B/S
P265/65R17,B/S,CANADA GX
P265/65R17,B/S
15 parts on this diagram · 2 diagrams in section
