DISC WHEEL & WHEEL CAP
04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE
TAIWAN SPEC
MEXICO SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
TAHITI SPEC
04423BFITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE(SPARE)
42601WHEEL, DISC
16X7J,#,TYPE A:REFER ILLUST.
16X7J,#,TYPE A:REFER ILLUST.
sub42611-V3010
16X7J,#,TAIWAN SPEC&REAR WHEEL BRAKE-16 INCH DISC(45S),TYPE A:REFER ILLUST.
sub42611-V3010
16X7J,#,REAR WHEEL BRAKE-16 INCH DISC(45S),TYPE A:REFER ILLUST.
sub42611-V3010
main42611-26190iGRH321,322;GDH321..RHD;GDH322..LHD..GSOB;GDH322..RHD..GSOB..N;GDH322..RHD..GSOB..6F;GDH322..SG..(D,N)..GEN;GDH322..LHD..SG..(P,Q)..GEN;GDH301,322,328..ARL,GCC,NZ,PH201902-202406
16X7J,#,TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
sub42611-V3010
main42611-26190iGRH321,322;GDH321..RHD;GDH322..LHD..GSOB;GDH322..RHD..GSOB..N;GDH322..RHD..GSOB..6F;GDH322..SG..(D,N)..GEN;GDH322..LHD..SG..(P,Q)..GEN;GDH301,322,328..ARL,GCC,NZ,PH201902-202406
16X7J,#,REAR WHEEL BRAKE-16 INCH DISC(48S)&TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
sub42611-V3010
17X7J,#,TYPE C:REFER ILLUST.
17X7J,#,TYPE C:REFER ILLUST.
17X7J,#,TYPE D:REFER ILLUST.
main42611-V3010iGRH321,322;GDH321..RHD;GDH300..6FC..ARL;GDH322..LHD..GSOB;GDH322..RHD..GSOB..N;GDH322..RHD..GSOB..6F;GDH322..SG..(ARL,GCC,GEN);GDH301,320,328..ARL,NZ,PH202407
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S),TYPE A:REFER ILLUST.
TYPE A:REFER ILLUST.
TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
EUROPE N1&REAR WHEEL BRAKE-DRUM BRAKE&TIRE & DISC WHEEL-215/70R16C,7J 108T,TYPE A:REFER ILLUST.
REAR WHEEL BRAKE-16 INCH DISC(48S)&TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPEA:REFER ILLUST.
EUROPE N1&TIRE & DISC WHEEL-215/70R16C,7J 108T,TYPE A:REFER ILLUST.
REAR WHEEL BRAKE-16 INCH DISC(48S),TYPE A:REFER ILLUST.
TIRE & DISC WHEEL-215/70R16C,7J 108T,TYPE A:REFER ILLUST.
42601AWHEEL, DISC (FOR SPARE)
16X7J,#,TYPE A:REFER ILLUST.
16X7J,#,TYPE A:REFER ILLUST.
sub42611-V3010
main42611-26190iGDH301..SG;GDH321..RHD;GDH301..GSOB..6FC;GDH322..LHD..GSOB;GDH322..ARL,GCC,NZ;GDH322..RHD..GSOB..N;GDH301..LHD..GSOB..6F;GDH322..RHD..GSOB..6F;GDH322..SG..(D,N)..GE201902-202406
16X7J,#,TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
sub42611-V3010
main42611-26190iGDH301..SG;GDH321..RHD;GDH301..GSOB..6FC;GDH322..LHD..GSOB;GDH322..ARL,GCC,NZ;GDH322..RHD..GSOB..N;GDH301..LHD..GSOB..6F;GDH322..RHD..GSOB..6F;GDH322..SG..(D,N)..GE201902-202406
16X7J,#,REAR WHEEL BRAKE-16 INCH DISC(48S)&TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
sub42611-V3010
17X7J,#,TYPE C:REFER ILLUST.
17X7J,#,TYPE C:REFER ILLUST.
17X7J,#,TYPE D:REFER ILLUST.
main42611-V3010iGDH300..5D;GDH321..RHD;GDH301..GSOB..6FC;GDH322..RHD..GSOB..N;GDH301..LHD..GSOB..6F;GDH300..4D..SP..(ARL,TH);GDH322..SG..(ARL,GCC,GEN);GDH300,301..4D..(PSOB,SG);GDH202407
TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPE A:REFER ILLUST.
TYPE A:REFER ILLUST.
main42611-V3010iGDH300..5D;GDH321..RHD;GDH301..GSOB..6FC;GDH322..RHD..GSOB..N;GDH301..LHD..GSOB..6F;GDH300..4D..SP..(ARL,TH);GDH322..SG..(ARL,GCC,GEN);GDH300,301..4D..(PSOB,SG);GDH202407
TIRE & DISC WHEEL-215/70R16C,7J 108T,TYPE A:REFER ILLUST.
main42611-V3010iGDH300..5D;GDH321..RHD;GDH301..GSOB..6FC;GDH322..RHD..GSOB..N;GDH301..LHD..GSOB..6F;GDH300..4D..SP..(ARL,TH);GDH322..SG..(ARL,GCC,GEN);GDH300,301..4D..(PSOB,SG);GDH202407
REAR WHEEL BRAKE-16 INCH DISC(48S)&TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI,TYPEA:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TYPE B:REFER ILLUST.
TYPE A:REFER ILLUST.
42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR
MEXICO SPEC
TAIWAN SPEC
REAR WHEEL BRAKE-16 INCH DISC(48S)
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
REAR WHEEL BRAKE-16 INCH DISC(48S)
42607AVALVE SUB-ASSY, TIRE PRESSURE MONITOR (FOR SPARE)
TAIWAN SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
MEXICO SPEC
42607DVALVE, TIRE PRESSURE MONITOR
REAR WHEEL BRAKE-16 INCH DISC(48S)
TAIWAN SPEC
MEXICO SPEC
TAHITI SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
42607EVALVE, TIRE PRESSURE MONITOR (FOR SPARE)
MEXICO SPEC
TAIWAN SPEC
TAHITI SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
42611GVALVE (FOR TUBELESS TIRE)
TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI
REAR WHEEL BRAKE-16 INCH DISC(45S)
REAR WHEEL BRAKE-16 INCH DISC(45S)&TIRE & DISC WHEEL-235/65R16C,7J 115T ALUMI
42611JVALVE (FOR TUBELESS TIRE SPARE)
42611UCAP, TIRE VALVE
TAHITI SPEC
TAIWAN SPEC
REAR WHEEL BRAKE-16 INCH DISC(48S)
MEXICO SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
42611WCAP, TIRE VALVE (FOR SPARE)
TAIWAN SPEC
MEXICO SPEC
TAHITI SPEC
MEXICO SPEC&REAR WHEEL BRAKE-16 INCH DISC(48S)
13 parts on this diagram · 3 diagrams in section
