RADIATOR GRILLE

0001 1 0002 1 0003 1 0005 1 0006 1

53111GRILLE, RADIATOR

main53111-35050iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

VW BRAND

main53111-35060iYN86..STD;RN85,90..ARL,GEN;LN8#,90,YN80,81,85,9#199108-199408

NO PAINT REQ.

main53111-35070iRN85..EFI;YN85..GEN,TH;RN85..RHD..GEN..IV3;LN86,RN85..RHD..TW1;LN80,85,90,RN90,YN80,9#..ARL,GEN,TH199108-199408

PLATED

main53111-35170iRN125199108-199308

PLATED

sub53111-35171

main53111-35171iLN9#199608-199806

PLATED

main53111-35250iRN85..T1..V;RN85..DLX..V199408-199708

NO PAINT REQ.,PAINTED GRILLE

main53111-35250iLN86..ARL,V;RN85,90,YN92..ARL,GEN;LN80,81,85,YN8#..SR5,STD199408-199909

NO PAINT REQ.

main53111-35280iRN8#,90,YN86..(DLX,SR5)..V199408-200106

PLATED

main53111-35350iRN8#,YN86..(DLX,SR5)..V199510-199607

PLATED,LIMITED VERSION FOR GCC

main53111-35350iRN8#,YN86..(DLX,SR5)..V199610-199708

PLATED,LIMITED EDITION(G.C.C)

main53111-89130iLN8#,RN8#,YN8#..STD198808-199108

NO PAINT REQ.

sub53111-89131

main53111-89131iLN85,90,RN8#,YN86,92..DLX198808-199108

NO PAINT REQ.

main53111-89132iLN80,85,90,YN80,85,87,92..GEN,TH198808-199108

PLATED

main53111-89133iLN85,90,RN90..SR5198808-199108

NO PAINT REQ.

main53111-89139iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

PLATED,VW BRAND

main53111-89143iRN125198907-199108

NO PAINT REQ.

main53111-89144iRN125198907-199108

PLATED

53119BPROTECTOR, RADIATOR GRILLE

main53119-35010iLN9#199108-199806

main53119-89105iLN8#,90,RN125,8#,90,YN8#,92198808-199108

53121AMOULDING, RADIATOR GRILLE

main53121-89103iRN8#,YN86..DLX..V198808-199008

LH

sub53121-89106

main53121-89103iLN85,90,RN90..SR5198808-199108

sub53121-89106

main53121-89105iLN80,85,90,YN80,85,87,92..GEN,TH198808-199108

CHROME PLATED PACKAGE

sub53121-89107

main53121-89105iRN8#,YN86..DLX..V198808-199008

CHROME PLATED PACKAGE,LH

sub53121-89107

main53121-89105iRN8#,YN86..(DLX,SR5)..V199008-199108

CHROME PLATED GRILLE,LH

sub53121-89107

main53121-89107iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

CHROME PLATED PACKAGE & VW BRAND

sub53121-89106

main53121-89108iLN85,90,RN85,YN92..DLX..(ARL,GEN)198808-199108

sub53121-89106

main53121-89108iRN8#,YN86..DLX..V198808-199008

RH

sub53121-89106

main53121-89109iRN8#,YN86..(DLX,SR5)..V199008-199108

CHROME PLATED GRILLE,RH

sub53121-89107

main53121-89109iRN8#,YN86..DLX..V198808-199008

CHROME PLATED PACKAGE,RH

sub53121-89107

main53121-89110iRN8#,YN86..(DLX,SR5)..V199008-199108

RH

main53121-89111iRN8#,YN86..(DLX,SR5)..V199008-199108

LH

53131ADOOR, HEADLAMP, RH

main53131-89116iLN85,90,RN90..SR5198808-199108

main53131-89117iRN8#,YN86..(DLX,SR5)..V198808-199108

CHROME PLATED PACKAGE

main53131-89118iRN125198907-199108

main53131-89122iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

VW BRAND

main53131-89123iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

CHROME PLATED PACKAGE & VW BRAND

main53131-89126iRN125198907-199108

CHROME PLATED PACKAGE

53132ADOOR, HEADLAMP, LH

main53132-89115iLN85,90,RN90..SR5198808-199108

main53132-89116iRN8#,YN86..DLX..V;LN8#,90,YN80,85,87,92..GEN,TH198808-199108

CHROME PLATED PACKAGE

main53132-89117iRN125198907-199108

main53132-89121iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

VW BRAND

main53132-89122iLN85..RHD..TW1..IV3;LN85..RHD..5F..GEN..CBU198910-199010

CHROME PLATED PACKAGE & VW BRAND

main53132-89125iRN125198907-199108

CHROME PLATED PACKAGE

53149BPROTECTOR, HEADLAMP DOOR, NO.3

main53149-35010iLN9#199108-199806

main53149-89101iLN8#,90,RN125,8#,90,YN8#,92198808-199108

9016740037

main90167-40037

9018906111

main90189-06111

9046712020

main90467-12020

9046712040

main90467-12040

10 parts on this diagram · 5 diagrams in section
