THROTTLE LINK & VALVE LEVER (ATM)

0001 1A750E,A750F 0002 1A343E

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-60030iGRN28#200908-201908

main35501-71010iTRN280200911-201108

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-60030iTRN280200911-201108

sub35505-26020

main35505-60070iGRN28#200908-201908

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iTRN280200908-201908

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iTRN280200908-201908

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iTRN280200908-201908

35556SHAFT, PARKING LOCK PAWL

main35556-30020iTRN280200911-201108

main35556-60020iGRN28#200908-201908

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iTRN280200908-201908

35557PAWL, PARKING LOCK

main35557-60020iTRN280200911-201108

main35557-60040iGRN28#200908-201908

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21002iTRN280200911-201108

main90949-03123iGRN28#200908-201908

35561SHAFT, MANUAL VALVE LEVER

main35561-35010iTRN280200911-201108

main35561-60030iGRN28#200908-201908

35573LEVER, TRANSMISSION CONTROL SHAFT, LH

main35573-60020iTRN280200908-201908

35595BRACKET, PARKING LOCK PAWL

main35595-60010iTRN280200911-201108

main35595-60030iGRN28#200908-201908

9008011250

main90080-11250

90170A0004

main90170-A0004

91611B0614

main91611-B0614

9413000802

main94130-00802

9451200800

main94512-00800

18 parts on this diagram · 2 diagrams in section
