REAR DISC BRAKE CALIPER & DUST COVER

04466PAD KIT, DISC BRAKE, REAR

main04466-42080i201811-202310

MARK NBK 478-XA5

04479ACYLINDER KIT, DISC BRAKE, REAR

main04479-42100i201811-202310

04946SHIM KIT, ANTI SQUEAL(FOR REAR DISC BRAKE)

main04946-33090i201811-202310

04948FITTING KIT, DISC BRAKE, REAR

main04948-12071i202204-202309

main04948-33060i201811-202204

31478CCAP, BLEEDER PLUG(FOR REAR DISC BRAKE)

main31478-30010i201811-202310

4601

47547CPLUG, BLEEDER(FOR REAR DISC BRAKE)

main47547-20010i201811-202310

47721DBOLT(FOR REAR DISC BRAKE CYLINDER MOUTING)

main90015-AA603i201811-202310

*8-1.00PX23-12.5

47769ABUSH, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47769-50010i201811-202310

47803COVER SUB-ASSY, DISC BRAKE DUST, REAR RH

main47803-33010i201811-202310

47804COVER SUB-ASSY, DISC BRAKE DUST, REAR LH

main47804-33010i201811-202310

47810ABOLT, HEXAGON(FOR REAR CALIPER)

main90105-12174i201811-202310

TYPE A:REFER ILLUST.

TYPE B:REFER ILLUST.

47814PIN, CYLINDER SLIDE, NO.1(FOR REAR DISC BRAKE)

main47814-78010i201811-202310

47815PIN, REAR CYLINDER SLIDE, NO.2(FOR REAR DISC BRAKE)

main47815-78010i201811-202310

47821MOUNTING, REAR DISC BRAKE CYLINDER, RH

main47821-10030i201811-202310

47822MOUNTING, REAR DISC BRAKE CYLINDER, LH

main47822-10030i201811-202310

47830CYLINDER ASSY, DISC BRAKE, REAR RH

main47830-42090i201811-202310

47831PISTON, REAR DISC BRAKE

main47831-48130i201811-202310

47850CYLINDER ASSY, DISC BRAKE, REAR LH

main47850-42080i201811-202310

47875RBOOT, BUSH DUST(FOR REAR DISC BRAKE)

main47875-33270i201811-202310

20 parts on this diagram · 1 diagram in section
