SWITCH & RELAY & COMPUTER

0001 1ENGINE & TRANSMISSION 0002 1ENGINE ROOM 0003 1ENGINE ROOM 0004 1INSTRUMENT PANEL 0005 1INSTRUMENT PANEL 0006 1CONSOLE 0007 1CONSOLE 0008 1CONSOLE 0009 1SWITCH 0010 1SWITCH 0011 1SWITCH 0012 1BODY 0013 1BODY 0014 1SEAT & BODY 0015 1SEAT & BODY 0016 1STEERING 0017 1STEERING 0018 1STEERING 0019 1STEERING

8202

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-52050iW100,101202111

84210SWITCH ASSY, BACK-UP LAMP

main84210-BZ120iW101..5F..PHL202111-202309

84248CLAMP, CENTER CLUSTER MODULE SWITCH HARNESS

main84248-BZ110iW101..5F..PHL202111-202309

84540SWITCH ASSY, NEUTRAL START

main84540-B2040iW100,101..CVT202111

84545SWITCH, NEUTRAL POSITION

main84545-BZ010iW101..5F..PHL202111-202309

89422ASENSOR, WATER TEMPERATURE

main89422-33030iW101..IDN;W100..IDN,PHL;W101..CVT..PHL202111

SAME 89422-BZ030

main89422-33030iW101..5F..PHL;W100,101..GCC,GEN,MXC,THAI,VN202201

main89422-BZ030iW100,101..(D,M)..IDN202111

SAME 89422-33030

89439BRACKET, SENSOR

main89439-BZ201iW100,101202111

89439DBRACKET, SENSOR, NO.1

main89439-BZ210iW100,101202111

89465ASENSOR, OXYGEN NO.2

main89465-BZ610iW100,101202111

89467BSENSOR, AIR FUEL RATIO

main89467-BZ020iW100,101202111

89615SENSOR, KNOCK CONTROL

main89615-20090iW101..5F..PHL;W100,101..GCC,GEN,MXC,THAI,VN202201

main89615-20090iW101..IDN;W100..IDN,PHL;W101..CVT..PHL202111

SAME 89615-BZ040

main89615-BZ040iW100,101..(D,M)..IDN202111

SAME 89615-20090

9004105592

main90041-05592

9004A10266

main9004A-10266

9004A43021

main9004A-43021

90105T0156

main90105-T0156

90105T0247

main90105-T0247

90119T0237

main90119-T0237

90119T0342

main90119-T0342

9043012221

main90430-12221

9043018032

main90430-18032

21 parts on this diagram · 19 diagrams in section
