REAR SPRING & SHOCK ABSORBER

0001 1W/O AVS 0002 1W/ AVS

42304CARRIER SUB-ASSY, REAR AXLE, RH

main42304-0E120iGYU15,TAUA1#,TAUH15202309-202403

(L)

main42304-0E130iTAUA15..S202403

(L)

main42304-48080iTAUA15..S202403

(J)

42305CARRIER SUB-ASSY, REAR AXLE, LH

main42305-0E120iTAUH15;GYU15,TAUA1#..G,M,N202403

(L)

main42305-0E130iGYU15,TAUA1#,TAUH15202309-202403

(L)

main42305-48080iTAUA15..S202403

(J)

48231ASPRING, COIL, REAR RH

main48231-0E880iTAUA10202309

main48231-0EA00iTAUA15..S202309

main48231-0EA10iTAUA15..M202309

TIRE & DISC WHEEL-255/55R20 MUD & SNOW TIRE

main48231-0EA20iTAUH15202309

main48231-0EA30iGYU15202312

48231BSPRING, COIL, REAR LH

main48231-0E880iTAUA10202309

main48231-0EA00iTAUA15..G,N202309

main48231-0EA10iTAUA15..G202309

TIRE & DISC WHEEL-255/55R20 MUD & SNOW TIRE

main48231-0EA20iTAUH15202309

main48231-0EA30iGYU15202312

48257CINSULATOR, REAR COIL SPRING, UPPER RH

main48257-0E060iTAUH15;GYU15,TAUA1#..G,M,N202309

48258BINSULATOR, REAR COIL SPRING, LOWER RH

main48258-0E120iTAUH15;GYU15,TAUA1#..G,M,N202309

48258CINSULATOR, REAR COIL SPRING, LOWER LH

main48258-0E120iTAUH15;GYU15,TAUA1#..G,M,N202309

48259AINSULATOR, REAR COIL SPRING, UPPER LH

main48257-0E060iTAUH15;GYU15,TAUA1#..G,M,N202309

48409CAM SUB-ASSY, REAR SUSPENSION TOE ADJUST

main48409-06010iGYU15,TAUA1#..G,M,N202309

48452RPLATE, REAR SUSPENSION TOE ADJUST, NO.2

main48452-0E020iGYU15,TAUA1#..G,M,N202309

48530ABSORBER ASSY, SHOCK, REAR RH

main48530-80B66iTAUH15202309

MARK 48530-48601

48530VABSORBER SET, SHOCK, REAR RH

main48530-8Z277iTAUA10202309

MARK 48530-0E371

main48530-8Z278iTAUA15..G,M,N202309

MARK 48530-0E381

main48530-8Z279iGYU15202312

MARK 48530-0E390

48540ABSORBER ASSY, SHOCK, REAR LH

main48540-80601iTAUH15202309

MARK 48540-48601

48540EABSORBER SET, SHOCK, REAR LH

main48530-8Z277iTAUA10202309

MARK 48530-0E371

main48530-8Z278iTAUA15..G,M,N202309

MARK 48530-0E381

main48530-8Z279iGYU15202312

MARK 48530-0E390

48553DCAP, REAR SHOCK ABSORBER, RH

main48553-06010iTAUH15;GYU15,TAUA1#..G,M,N202309

48553ECAP

main48553-52030iTAUH15;GYU15,TAUA1#..G,M,N202309

48554ACAP, REAR SHOCK ABSORBER, LH

main48553-06010iTAUH15;GYU15,TAUA1#..G,M,N202309

48703DWASHER(FOR REAR SUSPENSION ARM)

main48715-0E010iTAUH15;GYU15,TAUA1#..G,M,N202309

48703HWASHER, NO.1(FOR REAR SUSPENSION ARM)

main48715-0E020iTAUH15;GYU15,TAUA1#..G,M,N202309

48705LINK SUB-ASSY, TOE CONTROL, RH

main48705-48010iGYU15,TAUA1#..G,M,N202309

48706BLINK SUB-ASSY, TOE CONTROL, LH

main48706-48010iGYU15,TAUA1#..G,M,N202309

48710AARM ASSY, REAR SUSPENSION, NO.1 RH

main48710-0E120iTAUH15;GYU15,TAUA1#..G,M,N202309

48720AARM ASSY, REAR SUSPENSION, NO.1 LH

main48720-0E010iTAUH15;GYU15,TAUA1#..G,M,N202309

48730FARM ASSY, REAR SUSPENSION, NO.2 RH

main48730-0E150iTAUH15;GYU15,TAUA1#..G,M,N202309

48737COVER, REAR SUSPENSION ARM, RH

main48737-0E070iTAUH15;GYU15,TAUA1#..G,M,N202309

48738COVER, REAR SUSPENSION ARM, LH

main48738-0E070iTAUH15;GYU15,TAUA1#..G,M,N202309

48740FARM ASSY, REAR SUSPENSION, NO.2 LH

main48740-0E070iTAUH15;GYU15,TAUA1#..G,M,N202309

48750HSUPPORT ASSY, REAR SUSPENSION, RH

main48750-0E050iTAUH15;GYU15,TAUA1#..G,M,N202309

48760BSUPPORT ASSY REAR SUSPENSION, LH

main48750-0E050iTAUH15;GYU15,TAUA1#..G,M,N202309

48770AARM ASSY, UPPER CONTROL, REAR RH

main48770-48030iTAUH15;GYU15,TAUA1#..G,M,N202309

48790ARM ASSY, UPPER CONTROL, REAR LH

main48770-48030iTAUH15;GYU15,TAUA1#..G,M,N202309

48790EARM ASSY, UPPER CONTROL, REAR RH NO.2

main48790-0E030iTAUH15;GYU15,TAUA1#..G,M,N202309

48790FARM ASSY, UPPER CONTROL, REAR LH NO.2

main48790-0E040iTAUH15;GYU15,TAUA1#..G,M,N202309

48812BAR, STABILIZER, REAR

main48805-0E080iTAUA1#..G,M,N202309

main48805-0E100iTAUH15202309

main48805-0E110iGYU15202312

48830DLINK ASSY, REAR STABILIZER, RH

main48830-0E090iTAUH15;GYU15,TAUA1#..G,M,N202309

48840ALINK ASSY, REAR STABILIZER, LH

main48840-0E030iTAUH15;GYU15,TAUA1#..G,M,N202309

9008017221

main90080-17221

9008017224

main90080-17224

9010512415

main90105-12415

90105A0499

main90105-A0499

90109A0066

main90109-A0066

9011910A31

main90119-10A31

9011912456

main90119-12456

9011912484

main90119-12484

90119A0472

main90119-A0472

90119A0563

main90119-A0563

90119A0602

main90119-A0602

90119A0603

main90119-A0603

90119A0604

main90119-A0604

90170A0008

main90170-A0008

9017714006

main90177-14006

9017810022

main90178-10022

90178A0080

main90178-A0080

90178A0131

main90178-A0131

90178A0137

main90178-A0137

9418801441

main94188-01441

56 parts on this diagram · 2 diagrams in section
