FRONT SPRING & SHOCK ABSORBER

0001 1W/O AVS 0002 1W/ AVS

4802

48131SPRING, FRONT COIL, RH

main48131-0E630iTAUA15..G202309

TIRE & DISC WHEEL-255/55R20 MUD & SNOW TIRE

main48131-0E700iTAUA10;TAUA15..G,N202309

main48131-0E710iTAUH15202309

48132SPRING, FRONT COIL, LH

main48131-0E630iTAUA15..M202309

TIRE & DISC WHEEL-255/55R20 MUD & SNOW TIRE

main48131-0E700iTAUA10;TAUA15..G,N202309

main48131-0E710iTAUH15202309

main48131-0E720iGYU15202312

48157BINSULATOR, FRONT COIL SPRING, UPPER RH

main48157-0E070iTAUH15;GYU15,TAUA1#..G,M,N202309

48157CINSULATOR, FRONT COIL SPRING, UPPER LH

main48157-0E070iTAUH15;GYU15,TAUA1#..G,M,N202309

48158BINSULATOR, FRONT COIL SPRING, LOWER RH

main48158-06260iTAUH15;GYU15,TAUA1#..G,M,N202309

48158CINSULATOR, FRONT COIL SPRING, LOWER LH

main48158-06260iTAUH15;GYU15,TAUA1#..G,M,N202309

48331BBUMPER, FRONT SPRING, RH

main48331-0E100iTAUA15..S202309

48331CBUMPER, FRONT SPRING, LH

main48331-0E100iTAUA15..S202309

48505SEAT, FRONT SPRING, RH

main48159-0E010iTAUH15;GYU15,TAUA1#..G,M,N202309

48506SEAT, FRONT SPRING, LH

main48159-0E010iTAUA15..S202309

48510UABSORBER SET, SHOCK, FRONT RH

main48510-80000iTAUH15202309

MARK 48510-48741

main48510-8Z655iTAUA1#..G,M,N202309

MARK 48510-0E671

main48510-8Z657iGYU15202312

MARK 48510-0E690

48520GABSORBER SET, SHOCK, FRONT LH

main48520-80787iTAUH15202309

MARK 48520-48741

main48520-8Z465iTAUA1#..G,M,N202309

MARK 48520-0E671

main48520-8Z467iGYU15202312

MARK 48520-0E690

48559ACOVER, FRONT SHOCK ABSORBER DUST, RH NO.1

main48559-0R030iTAUH15;GYU15,TAUA1#..G,M,N202309

48559BCOVER, FRONT SHOCK ABSORBER DUST, LH NO.1

main48559-0R030iTAUH15;GYU15,TAUA1#..G,M,N202309

48603SUPPORT SUB-ASSY, FRONT SUSPENSION, RH

main48609-0E080iTAUH15;GYU15,TAUA1#..G,M,N202309

48603ANUT(FOR FRONT SUSPENSION SUPPORT)

main90178-A0077iTAUH15;GYU15,TAUA1#..G,M,N202309

48603DNUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER RH)

main90177-14007iTAUH15;GYU15,TAUA1#..G,M,N202309

(J)

main90177-A0019iTAUH15;GYU15,TAUA1#..G,M,N202309

(L)

48609SUPPORT SUB-ASSY, FRONT SUSPENSION, LH

main48609-0E080iTAUH15;GYU15,TAUA1#..G,M,N202309

48609ENUT(FOR FRONT SUPPORT TO FRONT SHOCK ABSORBER LH)

main90177-14007iTAUH15;GYU15,TAUA1#..G,M,N202309

(J)

main90177-A0019iTAUA15..S202309

(L)

48619BEARING, STRUT MOUNTING, RH

main48619-0E020iGYU15,TAUA1#,TAUH15202309-202402

sub48619-0E021

main48619-0E021iTAUH15;GYU15,TAUA1#..G,M,N202403

48619ABEARING, STRUT MOUNTING, LH

main48619-0E020iGYU15,TAUA1#,TAUH15202309-202402

sub48619-0E021

main48619-0E021iTAUH15;GYU15,TAUA1#..G,M,N202403

48691MDAMPER, FRONT SUSPENSION, RH

main48691-06020iTAUH15;GYU15,TAUA1#..G,M,N202309

48691NDAMPER, FRONT SUSPENSION, LH

main48691-06020iTAUA15..S202309

48810LINK ASSY, FRONT STABILIZER, LH

main48820-0E040iGYU15,TAUA1#,TAUH15202309-202407

main48820-0E070iTAUH15;GYU15,TAUA1#..G,M,N202408

48811BAR, STABILIZER, FRONT

main48804-0E070iTAUA15..S202309

48817DBOLT(FOR FRONT STABILIZER)

main90119-10994iTAUH15;GYU15,TAUA1#..G,M,N202309

(J)

main90119-A0474iTAUH15;GYU15,TAUA1#..G,M,N202309

(L)

48820ANUT(FOR FRONT STABILIZER LINK)

main90178-A0058iTAUH15;GYU15,TAUA1#..G,M,N202309

(L)

main94151-21441iTAUA15..S202309

(J)

48820BLINK ASSY, FRONT STABILIZER, RH

main48820-0E040iGYU15,TAUA1#,TAUH15202309-202407

main48820-0E070iTAUA15..S202408

48826FPROTECTOR, STABILIZER

main48826-0E070iTAUH15202309-202311

9011908D34

main90119-08D34

90119A0387

main90119-A0387

9046823005

main90468-23005

33 parts on this diagram · 2 diagrams in section
