DISC WHEEL & WHEEL CAP
04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE
sub04423-33060
42601WHEEL, DISC
18X7J, *SCHM,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub42611-48311
18X7J, *SCHM,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub42611-48451
17X6.5J, #,TYPE C:REFER ILLUST.
17X6.5J,MARK SD18M,TYPE B:REFER ILLUST.
17X6.5J,MARK SD19D,CANADA SPEC,TYPE B:REFER ILLUST.
18X7J, #,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
18X7J, #,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub4261A-48020
18X7J, #,CANADA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
18X7J, #,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
42601AWHEEL, DISC (FOR SPARE)
18X7J, *SCHM,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub42611-48311
18X7J, *SCHM,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub42611-48451
17X6.5J, #,TYPE C:REFER ILLUST.
17X6.5J,MARK SD18M,TYPE B:REFER ILLUST.
17X6.5J,MARK SD19D,CANADA SPEC,TYPE B:REFER ILLUST.
18X7J, #,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
18X7J, #,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
sub4261A-48020
18X7J, #,CANADA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
18X7J, #,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
42601CNUT, HUB (FOR AXLE)
TYPE A:REFER ILLUST.
TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE B:REFER ILLUST.
42603ORNAMENT SUB-ASSY, WHEEL HUB
*PSC,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
*ALU,TIRE & DISK WHEEL-235/55R18 ALUMI M+S,TYPE D:REFER ILLUST.
*CHR,TYPE B:REFER ILLUST.
42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR
sub42607-33022
42607AVALVE SUB-ASSY, TIRE PRESSURE MONITOR (FOR SPARE)
sub42607-33022
42611GVALVE (FOR TUBELESS TIRE)
KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
42611JVALVE (FOR TUBELESS TIRE SPARE)
KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
42611UCAP, TIRE VALVE
42611WCAP, TIRE VALVE (FOR SPARE)
CANADA SPEC
CANADA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
42652TIRE
235/55R18,MICHELIN,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
42652ATIRE (FOR SPARE)
235/55R18,MICHELIN,KOREA SPEC&TIRE & DISK WHEEL-235/55R18 ALUMI M+S
13 parts on this diagram · 2 diagrams in section
