REAR AXLE SHAFT & HUB

0001 1 0002 1 0003 1RH 0004 1 0005 1LH 0006 1

04438CBOOT KIT, REAR DRIVE SHAFT

main04437-48031iACU25,MCU25200011-200308

sub04429-22030

04438DBOOT KIT, REAR DRIVE SHAFT INBOARD JOINT

main04437-48020iACU25,MCU25200011-200308

sub04439-22030

42330SHAFT ASSY, REAR DRIVE, RH

main42340-48020iACU25,MCU25200011-200308

main42340-48030iACU25,MCU28200308

42340BSHAFT ASSY, REAR DRIVE, LH

main42340-48020iACU25,MCU25200011-200308

main42340-48030iACU25,MCU28200308

42341ARING, SNAP (FOR REAR DRIVE SHAFT)

main90520-23024iACU25,MCU25200011-200308

42346ACLAMP (FOR REAR DRIVE SHAFT OUTBOARD JOINT BOOT)

main42345-14010iACU25,MCU25200011-200308

ID=35.75

42346BCLAMP, NO. 2 (FOR RR DRIVE SHAFT OUTBOARD JOINT BOOT)

main90949-01473iACU25,MCU25200011-200308

42347ACLAMP (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)

main42345-14010iACU25,MCU25200011-200308

ID=35.75

42347BCLAMP, NO.2 (FOR REAR DRIVE SHAFT INBOARD JOINT BOOT)

main42345-14020iACU25,MCU25200011-200308

42360JOINT ASSY, REAR DRIVE SHAFT INBOARD

main42360-22040iACU25,MCU25200011-200308

42370SHAFT ASSY, REAR DRIVE OUTBOARD JOINT

main42370-49035iACU25,MCU25200011-200308

sub42370-49036

main42370-49125iACU25,MCU28200308

sub42370-49126

42380SHAFT ASSY, REAR DRIVE OUTBOARD JOINT, LH

main42370-49035iACU25,MCU25200011-200308

sub42370-49036

main42370-49125iACU25,MCU28200308

sub42370-49126

42451ADEFLECTOR, REAR WHEEL BEARING DUST, NO.1 RH

main43247-12010iACU25,MCU25200011-200308

42451BDEFLECTOR, REAR WHEEL BEARING DUST, NO.1 LH

main43247-12010iACU25,MCU25200011-200308

9017010191

main90170-10191

9020110068

main90201-10068

16 parts on this diagram · 6 diagrams in section
