E
EPC Data

INTERIOR LAMP

Parts diagram
7401
81205CBULB, ASH RECEPTACLE LAMP, REAR RH
main90981-11041i200008-200307
81205DBULB, ASH RECEPTACLE LAMP, REAR LH
main90981-11041i200008-200307
81230LAMP ASSY, COURTESY
main81230-50050i200008-200307
81230BBULB(FOR COURTESY LAMP)
main90981-11020i200008-200307
12V 3.8W
81231LENS, COURTESY LAMP
main81231-50050i200008-200307
81240LAMP ASSY, ROOM, NO.1
main81240-50080-A0i200008-200307
IVORY,TRIM04,RH
main81240-50080-A1i200008-200307
ECRU,TRIM03,05,RH
main81240-50080-B0i200008-200307
MD.CHARCOAL,TRIM1#,20,27,29,RH
main81240-50090-A0i200008-200307
IVORY,TRIM04,LH
main81240-50090-A1i200008-200307
ECRU,TRIM03,05,LH
main81240-50090-B0i200008-200307
MD.CHARCOAL,TRIM1#,20,27,29,LH
main81240-50100-A0i200307-200608
ECRU,TRIM00,08,RH
main81240-50100-A1i200307-200608
NEW IVORY,TRIM07,RH
main81240-50100-B0i200307-200608
NEW GRAY,TRIM1#,21,24,25,RH
main81240-50110-A0i200307-200608
ECRU,TRIM00,08,LH
main81240-50110-A1i200307-200608
NEW IVORY,TRIM07,LH
main81240-50110-B0i200307-200608
NEW GRAY,TRIM1#,21,24,25,LH
81240BBULB, ROOM LAMP, NO.1
main90981-12020i200008-200307
12V 8W
81241LENS, ROOM LAMP, NO.1
main81241-50110i200008-200307
RH
main81241-50120i200008-200307
LH
81250DLAMP ASSY, REAR ROOM, RH
main81250-50110-A0i200008-200307
IVORY,TRIM04
main81250-50110-A1i200008-200307
ECRU,TRIM03,05
main81250-50110-B0i200008-200307
MD.CHARCOAL,TRIM1#,20,27,29
main81250-50120-A0i200008-200307
W(REAR AIR CONDITIONER),IVORY,TRIM04
main81250-50120-A1i200008-200307
W(REAR AIR CONDITIONER),ECRU,TRIM03,05
main81250-50120-B0i200008-200307
W(REAR AIR CONDITIONER),MD.CHARCOAL,TRIM1#,20,27,29
main81250-50130-A0i200307-200608
W(REAR AIR CONDITIONER),ECRU,TRIM00,08
main81250-50130-A1i200307-200608
W(REAR AIR CONDITIONER),NEW IVORY,TRIM07
main81250-50130-B0i200307-200608
W(REAR AIR CONDITIONER),NEW GRAY,TRIM1#,21,24,25
main81250-50140-A0i200307-200608
ECRU,TRIM00,08
sub81250-50140
main81250-50140-A1i200307-200608
NEW IVORY,TRIM07
sub81250-50140
main81250-50140-B0i200307-200608
NEW GRAY,TRIM1#,21,24,25
sub81250-50140
81260ALAMP ASSY, MAP
main81260-50130-A0i200008-200307
CENTRAL AMERICA SPEC,IVORY,TRIM04
sub81260-50310
main81260-50130-A1i200307-200608
ECRU,TRIM00
sub81260-50310
main81260-50130-A1i200008-200307
CENTRAL AMERICA SPEC,ECRU,TRIM03
sub81260-50310
main81260-50130-A2i200307-200608
NEW IVORY,TRIM07
sub81260-50310
main81260-50130-B0i200008-200307
CENTRAL AMERICA SPEC,MD.CHARCOAL,TRIM1#,2#
sub81260-50310
main81260-50130-B1i200307-200608
NEW GRAY,TRIM1#,21,24
sub81260-50310
main81260-50140-A0i200008-200307
IVORY,TRIM04
sub81260-50271
main81260-50140-A1i200008-200307
ECRU,TRIM03
sub81260-50271
main81260-50140-B0i200008-200307
MD.CHARCOAL,TRIM1#,2#
sub81260-50271
main81260-50160-A0i200008-200107
W(NAVIGATION SYSTEM),IVORY,TRIM04
sub81260-50270
main81260-50160-A1i200008-200107
W(NAVIGATION SYSTEM),ECRU,TRIM03
sub81260-50270
main81260-50160-B0i200008-200107
W(NAVIGATION SYSTEM),MD.CHARCOAL,TRIM1#,2#
sub81260-50270
main81260-50170-A0i200008-200307
CENTRAL AMERICA SPEC & W(MOON ROOF),IVORY,TRIM04
sub81260-50330
main81260-50170-A1i200008-200307
CENTRAL AMERICA SPEC & W(MOON ROOF),ECRU,TRIM03
sub81260-50330
main81260-50170-A1i200307-200608
W(MOON ROOF),ECRU,TRIM00
sub81260-50330
main81260-50170-A2i200307-200608
W(MOON ROOF),NEW IVORY,TRIM07
sub81260-50330
main81260-50170-B0i200008-200307
CENTRAL AMERICA SPEC & W(MOON ROOF),MD.CHARCOAL,TRIM1#,2#
sub81260-50330
main81260-50170-B1i200307-200608
W(MOON ROOF),NEW GRAY,TRIM1#,21,24
sub81260-50330
main81260-50180-A0i200008-200307
W(MOON ROOF),IVORY,TRIM04
sub81260-50281
main81260-50180-A1i200008-200307
W(MOON ROOF),ECRU,TRIM03,05
sub81260-50281
main81260-50180-B0i200008-200307
W(MOON ROOF),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50281
main81260-50200-A0i200008-200107
W(NAVIGATION SYSTEM & MOON ROOF),IVORY,TRIM04
sub81260-50280
main81260-50200-A1i200008-200107
W(NAVIGATION SYSTEM & MOON ROOF),ECRU,TRIM03,05
sub81260-50280
main81260-50200-B0i200008-200107
W(NAVIGATION SYSTEM & MOON ROOF),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50280
main81260-50210-A0i200008-200107
W(MAYDAY SYSTEM),IVORY,TRIM04
sub81260-50290
main81260-50210-A1i200008-200107
W(MAYDAY SYSTEM),ECRU,TRIM03
sub81260-50290
main81260-50210-B0i200008-200107
W(MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,2#
sub81260-50290
main81260-50220-A0i200008-200107
W(MOON ROOF & MAYDAY SYSTEM),IVORY,TRIM04
sub81260-50300
main81260-50220-A1i200008-200107
W(MOON ROOF & MAYDAY SYSTEM),ECRU,TRIM03,05
sub81260-50300
main81260-50220-B0i200008-200107
W(MOON ROOF & MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50300
main81260-50270-A0i200107-200302
W(NAVIGATION SYSTEM),IVORY,TRIM04
sub81260-50271
main81260-50270-A1i200107-200302
W(NAVIGATION SYSTEM),ECRU,TRIM03
sub81260-50271
main81260-50270-B0i200107-200302
W(NAVIGATION SYSTEM),MD.CHARCOAL,TRIM1#,2#
sub81260-50271
main81260-50271-A0i200302-200307
W(NAVIGATION SYSTEM),IVORY,TRIM04
main81260-50271-A1i200302-200307
W(NAVIGATION SYSTEM),ECRU,TRIM03
main81260-50271-B0i200302-200307
W(NAVIGATION SYSTEM),MD.CHARCOAL,TRIM1#,2#
main81260-50280-A0i200107-200302
W(NAVIGATION SYSTEM & MOON ROOF),IVORY,TRIM04
sub81260-50281
main81260-50280-A1i200107-200302
W(NAVIGATION SYSTEM & MOON ROOF),ECRU,TRIM03,05
sub81260-50281
main81260-50280-B0i200107-200302
W(NAVIGATION SYSTEM & MOON ROOF),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50281
main81260-50281-A0i200302-200307
W(NAVIGATION SYSTEM & MOON ROOF),IVORY,TRIM04
sub81260-50281
main81260-50281-A1i200302-200307
W(NAVIGATION SYSTEM & MOON ROOF),ECRU,TRIM03,05
sub81260-50281
main81260-50281-B0i200302-200307
W(NAVIGATION SYSTEM & MOON ROOF),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50281
main81260-50290-A0i200107-200302
W(MAYDAY SYSTEM) OR W(NAVI & MAYDAY SYSTEM),IVORY,TRIM04
sub81260-50291
main81260-50290-A1i200107-200302
W(MAYDAY SYSTEM) OR W(NAVI & MAYDAY SYSTEM),ECRU,TRIM03
sub81260-50291
main81260-50290-B0i200107-200302
W(MAYDAY SYSTEM) OR W(NAVI & MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,2#
sub81260-50291
main81260-50291-A0i200302-200307
W(MAYDAY SYSTEM),IVORY,TRIM04
main81260-50291-A1i200302-200307
W(MAYDAY SYSTEM),ECRU,TRIM03
main81260-50291-B0i200302-200307
W(MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,2#
main81260-50300-A0i200107-200302
W(MOON ROOF & MAYDAY SYSTEM) OR W(NAVI & MOON ROOF & MAYDAY SYSTEM),IVORY,TRIM04
sub81260-50301
main81260-50300-A1i200107-200302
W(MOON ROOF & MAYDAY SYSTEM) OR W(NAVI & MOON ROOF & MAYDAY SYSTEM),ECRU,TRIM03,05
sub81260-50301
main81260-50300-B0i200107-200302
W(MOON ROOF & MAYDAY SYSTEM) OR W(NAVI & MOON ROOF & MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50301
main81260-50301-A0i200302-200307
W(MOON ROOF & MAYDAY SYSTEM),IVORY,TRIM04
sub81260-50400
main81260-50301-A1i200302-200307
W(MOON ROOF & MAYDAY SYSTEM),ECRU,TRIM03,05
sub81260-50400
main81260-50301-B0i200302-200307
W(MOON ROOF & MAYDAY SYSTEM),MD.CHARCOAL,TRIM1#,20,27,29
sub81260-50400
main81260-50350-A0i200307-200608
W(GARAGE DOOR OPENER),ECRU,TRIM00
sub81260-50360
main81260-50350-A1i200307-200608
W(GARAGE DOOR OPENER),NEW IVORY,TRIM07
sub81260-50360
main81260-50350-B0i200307-200608
W(GARAGE DOOR OPENER),NEW GRAY,TRIM1#,2#
sub81260-50360
main81260-50360-A0i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE),ECRU,TRIM00
main81260-50360-A1i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE),NEW IVORY,TRIM07
main81260-50360-B0i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE),NEW GRAY,TRIM1#,2#
main81260-50370-A0i200307-200608
W(GARAGE DOOR OPENER & MOON ROOF),ECRU,TRIM00,08
sub81260-50380
main81260-50370-A1i200307-200608
W(GARAGE DOOR OPENER & MOON ROOF),NEW IVORY,TRIM07
sub81260-50380
main81260-50370-B0i200307-200608
W(GARAGE DOOR OPENER & MOON ROOF),NEW GRAY,TRIM1#,21,24,25
sub81260-50380
main81260-50380-A0i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE & MOON ROOF),ECRU,TRIM00,08
sub81260-50380
main81260-50380-A1i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE & MOON ROOF),NEW IVORY,TRIM07
sub81260-50380
main81260-50380-B0i200307-200608
W(GARAGE DOOR OPENER & MICROPHONE & MOON ROOF),NEW GRAY,TRIM1#,21,24,25
sub81260-50380
main81260-50390-A0i200307-200312
W(GARAGE DOOR OPENER & MAYDAY SYSTEM),ECRU,TRIM00
sub81260-50390
main81260-50390-A1i200307-200312
W(GARAGE DOOR OPENER & MAYDAY SYSTEM),NEW IVORY,TRIM07
sub81260-50390
main81260-50400-A0i200307-200312
W(GARAGE DOOR OPENER & MAYDAY SYSTEM & MOON ROOF),ECRU,TRIM00,08
sub81260-50400
main81260-50400-A1i200307-200312
W(GARAGE DOOR OPENER & MAYDAY SYSTEM & MOON ROOF),NEW IVORY,TRIM07
sub81260-50400
main81260-50400-B0i200307-200312
W(GARAGE DOOR OPENER & MAYDAY SYSTEM & MOON ROOF),NEW GRAY,TRIM1#,21,24,25
sub81260-50400
81260CBULB(FOR MAP LAMP)
main90981-14004i200008-200307
12V 8W
81260HBULB(FOR MAP LAMP), NO.2
main90981-12005i200008-200307
12V 8W
81265CLENS, MAP LAMP, NO.1
main81265-50130i200008-200307
main81265-50170i200008-200307
W(MOON ROOF)
81290DLAMP ASSY, REAR ROOM, LH
main81290-50110-A0i200008-200307
IVORY,TRIM04
main81290-50110-A1i200008-200307
ECRU,TRIM03,05
main81290-50110-B0i200008-200307
MD.CHARCOAL,TRIM1#,20,27,29
main81290-50120-A0i200008-200307
W(REAR AIR CONDITIONER),IVORY,TRIM04
main81290-50120-A1i200008-200307
W(REAR AIR CONDITIONER),ECRU,TRIM03,05
main81290-50120-B0i200008-200307
W(REAR AIR CONDITIONER),MD.CHARCOAL,TRIM1#,20,27,29
main81290-50130-A0i200307-200608
W(REAR AIR CONDITIONER),ECRU,TRIM00,08
main81290-50130-A1i200307-200608
W(REAR AIR CONDITIONER),NEW IVORY,TRIM07
main81290-50130-B0i200307-200608
W(REAR AIR CONDITIONER),NEW GRAY,TRIM1#,21,24,25
main81290-50140-A0i200307-200608
ECRU,TRIM00,08
sub81290-50140
main81290-50140-A1i200307-200608
NEW IVORY,TRIM07
sub81290-50140
main81290-50140-B0i200307-200608
NEW GRAY,TRIM1#,21,24,25
sub81290-50140
81330LAMP ASSY, LUGGAGE COMPARTMENT, NO.1
main81330-50021i200008-200307
81330BBULB, LUGGAGE COMPARTMENT LAMP
main90981-11020i200008-200307
12V 3.8W
81331LENS, LUGGAGE COMPARTMENT LAMP
main81331-50010i200008-200307
81340BBULB (FOR VANITY LAMP)
main90981-14007i200008-200307
12V 3W,FRONT
main90981-14007i200307
12V 3W,REAR
81340HLAMP ASSY, VANITY, RH
main81340-50150-A2i200307-200608
ECSAINE TYPE,ECRU,TRIM0#,REAR
main81340-50150-B1i200307-200608
ECSAINE TYPE,NEW GRAY,TRIM21,25,REAR
main81340-50160-A1i200307-200608
NEW IVORY,TRIM07,REAR
main81340-50160-A2i200307-200608
ECRU,TRIM00,REAR
main81340-50160-B1i200307-200608
NEW GRAY,TRIM1#,21,24,REAR
main81350-50110-A3i200008-200307
IVORY,TRIM04
main81350-50110-A4i200008-200307
ECRU,TRIM03,05
main81350-50110-A4i200307-200608
ECRU,TRIM00,08,FRONT
main81350-50110-A5i200307-200608
NEW IVORY,TRIM07,FRONT
main81350-50110-B2i200008-200307
MEDIUM CHARCOAL,TRIM1#,20,27,29
main81350-50110-B3i200307-200608
NEW GRAY,TRIM1#,21,24,25,FRONT
81340JLAMP ASSY, VANITY, LH
main81340-50120-A3i200008-200307
IVORY,TRIM04
main81340-50120-A4i200008-200307
ECRU,TRIM03,05
main81340-50120-A4i200307-200608
ECRU,TRIM00,08,FRONT
main81340-50120-A5i200307-200608
NEW IVORY,TRIM07,FRONT
main81340-50120-B2i200008-200307
MEDIUM CHARCOAL,TRIM1#,20,27,29
main81340-50120-B3i200307-200608
NEW GRAY,TRIM1#,21,24,25,FRONT
main81340-50150-A2i200307-200608
ECSAINE TYPE,ECRU,TRIM0#,REAR
main81340-50150-B1i200307-200608
ECSAINE TYPE,NEW GRAY,TRIM21,25,REAR
main81340-50160-A1i200307-200608
NEW IVORY,TRIM07,REAR
main81340-50160-A2i200307-200608
ECRU,TRIM00,REAR
main81340-50160-B1i200307-200608
NEW GRAY,TRIM1#,21,24,REAR
81341LENS, VANITY LAMP
main81341-30090i200008-200307
FRONT
main81341-50150i200307
REAR
81360BBULB, STEP OR SPOT LAMP
main81090-50010i200008-200307
12V 1.8W
8202
8715
9016740044
main90167-40044
9018904102
main90189-04102
9354013006
main93540-13006
9356054016
main93560-54016

29 parts on this diagram · 3 diagrams in section

INTERIOR LAMP — Toyota Parts Diagram with OEM Numbers & Prices | EPC Data
