REAR SPRING & SHOCK ABSORBER

42210BUSH ASSY, LOWER BALL

main42210-14010iMA70198808-199305

42304CARRIER SUB-ASSY, REAR AXLE, RH

main42304-14010iMA70198808-199305

42304CSPACER (FOR REAR AXLE CARRIER)

main90560-14009iMA70198808-199305

42305CARRIER SUB-ASSY, REAR AXLE, LH

main42305-14010iMA70198808-199305

43324ACOVER, UPPER BALL JOINT DUST

main43324-14010iMA70198808-199305

48190RCAM ASSY, CAMBER ADJUST

main48190-14010iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199305

48198RCAM, REAR SUSPENSION CAMBER ADJUST, NO.2

main48198-14010iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199305

sub48198-50011

48231SPRING, COIL, REAR

main48231-1B010iMA70..LB198808-199008

main48231-1B020iMA70..SPR198808-199008

main48231-1B090iMA70199008-199305

48341BUMPER, REAR SPRING

main48341-14030iMA70198808-199008

main48341-14040iMA70199008-199305

48530ABSORBER ASSY, SHOCK, REAR RH

main48530-19105iMA70..USA199008-199305

W(TEMS)

sub48530-19106

main48530-19135iMA70..USA198808-199008

W(TEMS)

sub48530-19136

main48530-19155iMA70198808-199008

sub48530-19156

main48530-19335iMA70199008-199305

MARK 48530-14320

sub48530-19336

48540ABSORBER ASSY, SHOCK, REAR LH

main48530-19105iMA70..USA199008-199305

W(TEMS)

sub48530-19106

main48530-19135iMA70..USA198808-199008

W(TEMS)

sub48530-19136

main48530-19155iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199008

sub48530-19156

main48530-19335iMA70199008-199305

MARK 48530-14320

sub48530-19336

48553ACAP, SHOCK ABSORBER

main48553-14010iMA70..USA198808-199305

W(TEMS),RH

main48553-14020iMA70..USA198808-199305

W(TEMS),LH

main48553-14030iMA70198808-199305

48702BUSH SUB-ASSY, UPPER CONTROL ARM

main48702-14030iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199305

48703CNUT(FOR REAR SUSPENSION ARM)

main90170-14006iMA70198808-199112

main90170-14026iMA70199112-199305

48703EBOLT(FOR REAR SUSPENSION ARM)

main90119-14016iMA70198808-199009

*14-1.5PX73-67

sub90119-14035

main90119-14035iMA70199009-199305

*14-1.5PX70-64

48710AARM ASSY, REAR SUSPENSION, NO.1 RH

main48710-14100iMA70198808-199305

48715ABOLT, HEXAGON(FOR UPPER CONTROL ARM)

main90105-14041iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199305

FR

main90119-14016iMA70198808-199009

RR

sub90119-14035

main90119-14035iMA70199009-199305

RR

48720AARM ASSY, REAR SUSPENSION, NO.1 LH

main48720-14060iMA70198808-199305

48725BUSH, LOWER CONTROL ARM

main48725-14040iMA70198808-199305

48725BBUSH, REAR SUSPENSION ARM, NO.1

main48725-14010iMA70198808-199305

48725CBUSH, REAR SUSPENSION ARM, NO.2

main48725-14020iMA70198808-199008

main48725-14050iMA70199008-199305

48730AARM ASSY, REAR SUSPENSION, NO.2

main48730-14010iMA70198808-199008

sub48730-14020

main48730-14020iMA70199008-199305

48750SUPPORT ASSY, REAR SUSPENSION

main48750-14011iMA70198808-199008

main48750-14030iMA70199008-199305

48750ANUT(FOR REAR SUPPORT TO REAR SHOCK ABSORBER)

main94187-11200iMA70198808-199305

sub90177-12002

48770AARM ASSY, UPPER CONTROL, REAR RH

main48770-19015iMA70198808-199305

48780AROD ASSY, STRUT, REAR

main48780-14011iMA70198808-199305

48780BBOLT(FOR STRUT ROD)

main90105-14042iMA70198808-199305

BODY SIDE

main90119-14016iMA70..TWC;MA70..4FC..TWT;MA70..SPR..5F..TWT;MA70..LB..5F..TWT..USA198808-199009

CARRIER SIDE

sub90119-14035

main90119-14035iMA70199009-199305

CARRIER SIDE

48780CNUT(FOR STRUT ROD)

main90179-14028iMA70198808-199009

main90179-14045iMA70199009-199305

48780DBUSH, STRUT ROD

main48725-14030iMA70198808-199305

48790ARM ASSY, UPPER CONTROL, REAR LH

main48790-19015iMA70198808-199305

48812BAR, STABILIZER, REAR

main48812-14200iMA70198808-199008

main48812-14210iMA70199008-199305

48815RBUSH, STABILIZER(FOR REAR)

main48818-14030iMA70198808-199008

main48818-14040iMA70199008-199305

48824RBRACKET, STABILIZER(FOR REAR)

main48832-14040iMA70198808-199305

48830LINK ASSY, REAR STABILIZER

main48830-14040iMA70198808-199305

9011908588

main90119-08588

9011914018

main90119-14018

9017014006

main90170-14006

9017014026

main90170-14026

9017908054

main90179-08054

9017910054

main90179-10054

9017912027

main90179-12027

9017914015

main90179-14015

9017914037

main90179-14037

9020114020

main90201-14020

9411040800

main94110-40800

9418040500

main94180-40500

46 parts on this diagram · 1 diagram in section
