DISC WHEEL & WHEEL CAP

0001 1 0002 1

04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE

main04423-33030iAHV40..JPP200603-201108

sub04423-33060

42601WHEEL, DISC

main42611-33531iAHV40..JPP200603-200901

16X6.5J,#,TYPE D:REFER ILLUST.

sub42611-33620

main4261A-33040iAHV40..JPP200901-201108

16X6.5J,#,TYPE F:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-33510iAHV40..JPP200603-201108

17X4T,TYPE E:REFER ILLUST.

42601CNUT, HUB (FOR AXLE)

main90942-01033iAHV40..JPP200603-200901

TYPE B:REFER ILLUST.

main90942-01033iAHV40..JPP200901-201108

42603ORNAMENT SUB-ASSY, WHEEL HUB

main42603-44070iAHV40..JPP200603-201108

*ALU,TYPE A:REFER ILLUST.

42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR

main42607-33011iAHV40..JPP200603-201108

sub42607-33012

42611GVALVE (FOR TUBELESS TIRE)

main90942-05009iAHV40..JPP200603-201108

CANADA SPEC

main90942-05009iAHV40..JPP200903-201108

KOREA SPEC

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iAHV40..JPP200603-201108

42611UCAP, TIRE VALVE

main90942-05039iAHV40..JPP200603-201108

42652TIRE

main42652-06680iAHV40..JPP200603-200901

P215/60R16,*B/S

sub42652-06681

main42652-06730iAHV40..JPP200603-200901

P215/60R16,MICHELIN

42652ATIRE (FOR SPARE)

main42652-30C00iAHV40..JPP200603-200901

T155/70D17,*T/Y

main42652-58050iAHV40..JPP200603-200901

T155/70D17,*D/L

main42652-58060iAHV40..JPP200603-200901

T155/70D17,*Y/H

11 parts on this diagram · 2 diagrams in section
