THROTTLE LINK & VALVE LEVER (ATM)

3312

35409DSPRING SUB-ASSY, MANUAL DETENT

main35409-48060iAXVA70¥400201703-201811

35501ROD SUB-ASSY, PARKING LOCK

main35501-33030iAXVA70¥1,240201703-201811

35505LEVER SUB-ASSY, MANUAL VALVE

main35502-33010iAXVA70¥230201703-201811

35506SHAFT SUB-ASSY, MANUAL VALVE LEVER

main35503-48010iAXVA70¥300201703-201811

NO.2

main35506-33030iAXVA70201703-201811

NO.1,TMC:REFER 35-01

main35506-33040iAXVA70201705-201811

NO.1,AISIN:SEE 35-01

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90301-09173iAXVA70¥140201703-201811

35506JSPRING, RETAINER (FOR MANUAL VALVE LEVER SHAFT)

main90524-09004iAXVA70¥60201703-201811

35556SHAFT, PARKING LOCK PAWL

main35556-48030iAXVA70¥520201703-201811

TOYOTA:REFER 35-01

main35556-48040iAXVA70201705-201811

AISIN:REFER 35-01

35557PAWL, PARKING LOCK

main35557-33040iAXVA70¥2,810201703-201811

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-29030iAXVA70¥180201703-201811

35572ALEVER, TRANSMISSION CONTROL SHAFT

main35572-48050iAXVA70¥810201703-201811

sub35572-48051¥740

35596PLATE, PAWL STOPPER

main35596-33020iAXVA70201703-201811

35598SLEEVE, PARKING LOCK

main35598-48040iAXVA70¥770201703-201811

8401

9031112002

main90311-12002¥270

9155180612

main91551-80612¥60

9155180614

main91551-80614¥60

9413000802

main94130-00802¥90

9451200800

main94512-00800¥80

19 parts on this diagram · 1 diagram in section
