CENTER SUPPORT & PLANETARY SUN GEAR (ATM)

35608SPRING SUB-ASSY, 2ND BRAKE PISTON RETURN

main35608-32010iVZV21..4FC198906-199107

35624PISTON, 2ND BRAKE

main35624-32010iVZV21..4FC198906-199107

35624ARING, O (FOR 2ND BRAKE PISTON)

main90301-99021iVZV21..4FC198906-199107

INNER

main90301-99023iVZV21..4FC198906-199107

OUTER

35648PLATE, CLUTCH (FOR 2ND BRAKE)

main35648-32030iVZV21..4FC198906-199107

T=1.8

35664CYLINDER, 2ND BRAKE

main35664-32010iVZV21..4FC198906-199107

35664ABOLT (FOR 2ND BRAKE CYLINDER)

main90109-06060iVZV21..4FC198906-199107

35664BRING, HOLE SNAP (FOR 2ND BRAKE CYLINDER)

main90521-99013iVZV21..4FC198906-199107

35676FLANGE, BRAKE (FOR 2ND BRAKE)

main35676-32010iVZV21..4FC198906-199107

T=3.5

sub35676-12030

35677DISC, CLUTCH (FOR 2ND BRAKE)

main35677-32050iVZV21..4FC198906-199106

main35677-33020iVZV21..4FC199106-199107

sub35677-33021

35706HGEAR SUB-ASSY, PLANETARY SUN

main35706-32021iVZV21..4FC198906-199105

sub35706-33012

35706JBEARING, THRUST NEEDLE ROLLER (FOR PLANETARY SUN GEAR)

main90374-30008iVZV21..4FC198906-199105

sub90374-30014

35755DRUM, SUN GEAR INPUT

main35755-32030iVZV21..4FC198906-199105

35755ARING, SHAFT SNAP (FOR SUN GEAR INPUT DRUM)

main90520-36017iVZV21..4FC198906-199105

T=1.4,ID=36

35790CLUTCH ASSY, 1 WAY

main35790-32031iVZV21..4FC198906-199107

14 parts on this diagram · 1 diagram in section
