DISC WHEEL & WHEEL CAP

0001 1 0002 1

04423FITTING KIT, TIRE PRESSURE MONITOR OR BALANCER VALVE

main04423-33030iAZE151200703-201003

sub04423-33060

42601WHEEL, DISC

main42611-12A10iAZE151200703-201003

16X6.5J, #,TYPE A:REFER ILLUST.

42601AWHEEL, DISC (FOR SPARE)

main42611-12B30iAZE151200703-200911

17X4T,TYPE C:REFER ILLUST.

main42611-75100iAZE151200911-201003

17X4T,TYPE C:REFER ILLUST.

sub42611-75101

42601CNUT, HUB (FOR AXLE)

main90942-01007iAZE151200703-201003

TYPE C:REFER ILLUST.

42607VALVE SUB-ASSY, TIRE PRESSURE MONITOR

main42607-33011iAZE151200703-201003

sub42607-33012

42611JVALVE (FOR TUBELESS TIRE SPARE)

main90942-05009iAZE151200703-201003

42611UCAP, TIRE VALVE

main90942-05039iAZE151200703-201003

42652TIRE

main42652-12F20iAZE151200703-201003

P205/55R16,*B/S

main42652-12F30iAZE151200703-201003

P205/55R16,*D/L

42652ATIRE (FOR SPARE)

main42652-12F10iAZE151200703-201003

T135/70D17

9 parts on this diagram · 2 diagrams in section
