DISC WHEEL & WHEEL CAP
42601WHEEL, DISC
13X4.5J,SILVER,041 ,164 ,205 ,3E6 ,741 ,8D8 ,8G1
sub42611-10220
13X4.5J,SILVER,041 ,164 ,205 ,3E6 ,3H4 ,4H6 ,4J3 ,741 ,8D8 ,8G1 ,168
sub42611-16150
13X5J,DARK GRAY,041 ,164 ,168 ,205 ,3E6 ,3H4 ,4H6 ,741 ,8D8 ,8G1
sub42611-20300
13X5J,DARK GRAY,041 ,164 ,205 ,3E6 ,3H4 ,4H6 ,4J3 ,741 ,8D8 ,8G1
sub42611-20300
13X5J,DARK GRAY,041 ,164 ,205 ,3E6 ,3H4 ,4H6 ,4J3 ,741 ,8D8 ,8G1 ,168
sub42611-20300
42601AWHEEL, DISC (FOR SPARE)
42601DWEIGHT, BALANCE (FOR DISC WHEEL)
20G,T=8
30G,T=10
40G,T=9.5
50G,T=9.5
60G,T=9.5
70G,T=9.5
80G,T=9.5
10G,T=7.5
15G
25G
35G
45G
55G
65G
75G
5G
42603ORNAMENT SUB-ASSY, WHEEL HUB
42611GVALVE (FOR TUBELESS TIRE)
42621CAP, WHEEL
42652TIRE
main42652-12670iEL31..5DS..STD..USA;EL31..2DS..STD..EFI;EL31..(2DS,3DS)..(3FC,5F)..(BASE,STD)..CBR198808-199009
155SR13,ALL SEASON
155SR13
P145/80R13 SP4N
42652ATIRE (FOR SPARE)
T105/70D14
9 parts on this diagram · 1 diagram in section
