ENGINE OIL PUMP

0001 1 0002 1 0003 1 0004 1

1105

1106

15104STRAINER SUB-ASSY, OIL

main15104-0M020i1NZFE..NCP150..TAIW201409-201604

(L)

main15104-0M030i1NZFE..NCP150..C201403-201609

(L)

main15104-0Y010i1NRFE,2NRFE..NSP150,151..(GCC,IDN,MA)..(D,G,V);2NRFE,3NRFE..NSP151,152..CVT..(IDN,MA,TH,VN)..R201607-202302

*230 OR *432

main15104-0Y010i1NRFE,2NRFE..NSP150,151..GCC,GEN,PH,VN201605-202302

*264

main15104-0Y010i2NRFE..NSP151..B201904-202011

*419

main15104-21022i2NZFE..NCP151201403-201609

(J)

main15104-47040i3NRFE..NSP152201310-201607

main15104-47060i1NRFBE,2NR#..NSP150,151..H201806-201910

15104ARING, O(FOR OIL STRAINER)

main90301-22018i3NRFE..NSP152201310-201607

main90301-T0061i2NRFE..NSP151..C201605-202302

*264

main90301-T0061i1NRFE,2NRFE,3NRFE..NSP15#..GCC,GEN,PH,TH,VN201607-202302

*230 OR *432

main90301-T0061i2NRFE..NSP151..B201904-202011

*419

main96723-19018i1NRFBE,2NR#..NSP150,151..H201806-201910

90105T0117

main90105-T0117

5 parts on this diagram · 4 diagrams in section
