SWITCH & RELAY & COMPUTER

0001 1����� & ��������� 0002 1����� & ��������� 1/2 0003 1����� & ��������� 2/2 0004 1����� & ��������� 1/2 0005 1����� & ��������� 2/2 0006 1�������������������(A861E) 0007 1�������������������(AK60E) 0008 1�������� �������� & ��� 0009 1�������� �������� 0010 1��� 0011 1��� 0012 1��� 2/2 0013 1������������ 0014 1������� 0015 1��� 0016 1��� & ��� 0017 1��� & ��� 0018 1�������

83420GAGE ASSY, WATER TEMPERATURE SENDER

mainS834201250iXZB60..5F;XZB60..09S;XZB70..21S,29S,49S;XZB70,80..(13S,24S)..HDCR201701-202312

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-28010iGDB60,70,80202201-202412

main83530-60010iGDB60,70,80202201-202412

main83530-E0220iXZB60,70,80201701-201909

sub83530-E0250

main83530-E0250iXZB60..5F;XZB60..09S;XZB70..21S,29S,49S;XZB70,80..(13S,24S)..HDCR201909-202312

84210SWITCH ASSY, BACK-UP LAMP

main84210-52050iXZB60,70..5F201701-202312

84540SWITCH ASSY, NEUTRAL START

main84540-36120iGDB60,70,80202201-202412

main84540-37050iXZB70..(09S,24S)..6FC..DCR;XZB60,80..(13S,25S,39S)..6FC..DCR201701-202312

84540CSWITCH ASSY, NEUTRAL (FOR EXHAUST BRAKE)

main84540-36100iXZB60,70..5F201701-202312

89420MSENSOR ASSY, AIR PRESSURE

main89421-E0050iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201701-202312

89424GSENSOR, INLET AIR TEMPERATURE

main89424-E0040iXZB60..5F;XZB60..09S;XZB70..21S,29S,49S;XZB70,80..(13S,24S)..HDCR201701-202312

89425SENSOR, EXHAUST GAS TEMPERATURE

main89425-37380iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201908-202312

main89425-71070iGDB60,70,80202201-202412

main89425-E0210iXZB60,70201701-201908

89425ASENSOR, EXHAUST GAS TEMPERATURE, NO.2

main89425-36060iXZB60..5F;XZB60..09S;XZB70..21S,29S,49S;XZB70,80..(13S,24S)..HDCR201701-202312

main89425-71080iGDB60,70,80202201-202412

89425BSENSOR, EXHAUST GAS TEMPERATURE, NO.3

main89425-36110iXZB60,70201701-201908

main89425-37200iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201908-202312

main89425-71090iGDB60,70,80202201-202412

89425CSENSOR, EXHAUST GAS TEMPERATURE, NO.4

main89425-36121iXZB60,70201701-201908

main89425-36130iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201908-202312

main89425-36150iGDB60,70,80202201-202412

89439BRACKET, SENSOR

main89439-36140iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201908-202312

89439DBRACKET, SENSOR, NO.1

main89439-36060iXZB70201701-201908

main89439-36070iXZB60201701-201908

main89439-36080iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201908-202312

main8946A-60190iGDB60,70,80202201-202412

89458DSENSOR, FUEL PRESSURE

main89458-E0030iXZB60,70201701-201908

89463ASENSOR, NITROGEN OXIDES

main89463-36010iXZB60,70201701-201908

89480ASENSOR ASSY, DIFFERENTIAL PRESSURE

main89480-36030iXZB60,70201701-201908

89491SENSOR, ENGINE OIL LEVEL

main89491-26190iGDB60,70,80202201-202412

mainS834601580iXZB60..09S;XZB60,70..5F;XZB70,80..(13S,24S)..HDCR;XZB70..(21S,29S,49S)..6FC201701-202312

82702E2L21BRACKET SUB-ASSY, WIRING HARNESS

main82702-E2L21

827111E340WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-1E340

8271134490WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-34490

8271536260BRACKET,WIRING HARNESS CLAMP

main82715-36260

8271536410BRACKET,WIRING HARNESS CLAMP

main82715-36410

827153VM31BRACKET,WIRING HARNESS CLAMP

main82715-3VM31

827153VM50BRACKET,WIRING HARNESS CLAMP

main82715-3VM50

9043018008

main90430-18008

9155180816

main91551-80816

9165140825

main91651-40825

9165160616

main91651-60616

91651B0820

main91651-B0820

9167380820

main91673-80820

9415180600

main94151-80600

SH51110612

mainSH511-10612

SH51110614

mainSH511-10614

SH55210816

mainSH552-10816

SH55211018

mainSH552-11018

SL72201010

mainSL722-01010

SZ43010005WASHER, SOFT, NO.1

mainSZ430-10005

SZ43014002WASHER, SOFT, NO.1

mainSZ430-14002

38 parts on this diagram · 18 diagrams in section
