THROTTLE LINK & VALVE LEVER (ATM)

0001 1A343F 0002 1A750F 0003 1AC60F

3312

35501ROD SUB-ASSY, PARKING LOCK

main35501-60030iGRJ15#¥1,900200908-201506

main35501-71010iTRJ150¥2,730200908-201506

main35501-71020iGDJ15#,TRJ150¥1,610201506

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-26010iGDJ15#,TRJ150¥870201506

main35505-60030iTRJ150¥1,840200908-201506

sub35505-26020¥1,530

main35505-60070iGRJ15#¥1,470200908-201506

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iGDJ15#,TRJ150¥160200908-201506

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-12002iGRJ15#,TRJ150¥270200908-201506

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20025iGDJ15#,TRJ150¥210200908-201506

35556SHAFT, PARKING LOCK PAWL

main35556-30020iTRJ150¥440200908-201506

main35556-60020iGRJ15#¥380200908-201506

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iGRJ15#,TRJ150¥110200908-201506

35557PAWL, PARKING LOCK

main35557-60020iTRJ150¥2,490200908-201506

main35557-60040iGRJ15#¥3,100200908-201506

main35557-71010iGDJ15#,TRJ150¥2,810201506

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21002iTRJ150¥190200908-201506

main90949-03123iGRJ15#¥120200908-201506

35561SHAFT, MANUAL VALVE LEVER

main35561-35010iTRJ150¥2,070200908-201506

main35561-60030iGRJ15#¥1,860200908-201506

35573LEVER, TRANSMISSION CONTROL SHAFT, LH

main35573-60020iGRJ15#,TRJ150¥610200908-201506

main35573-71010iGDJ15#,TRJ150¥510201506

35595BRACKET, PARKING LOCK PAWL

main35595-60010iTRJ150¥1,460200908-201506

main35595-60030iGRJ15#¥730200908-201506

main35595-71010iGDJ15#,TRJ150¥800201506

91611B0614

main91611-B0614¥110

9413000802

main94130-00802¥90

9451200800

main94512-00800¥80

16 parts on this diagram · 3 diagrams in section
