COWL PANEL & WINDSHIELD GLASS

55701PANEL SUB-ASSY, COWL

main55701-90074iBJ4#198008-198410

55702PANEL SUB-ASSY,COWL TOP, INSIDE

main55702-90305iBJ4#198008-198110

main55702-90800iBJ4#198110-198205

main55702-90803iBJ4#198205-198410

55957GUIDE, DEFROSTER

main55956-90300iBJ4#198008-198410

RH

main55957-90300iBJ4#198008-198410

LH

55957ACLIP(FOR DEFROSTER GUIDE)

main90467-07003×8iBJ4#198008-198410

56111GLASS, WINDSHIELD

main56111-90300iBJ4#198008-198410

*ZT,T=5.0

sub56111-90301

56121WEATHERSTRIP, WINDSHIELD

main56121-90300iBJ4#198008-198410

56211SPACER, WINDSHIELD

main56211-90300iBJ4#198008-198106

main56211-90801iBJ4#198106-198110

main56211-90802iBJ4#..VKC198110-198410

56301FRAME SUB-ASSY, WINDSHIELD

main56301-90800iBJ4#..V198008-198410

main56301-90801iBJ4#..TPC198008-198410

FOLDING TYPE

main56301-90803iBJ4#..TPC198008-198410

56301BPLUG, HOLE(FOR ROOM LAMP)

main90950-01006iBJ4#..TPC198008-198410

56301CPLUG, HOLE(FOR WINDSHIELD FRAME)

main90950-01065×7iBJ4#..TPC198008-198410

56306HINGE SUB-ASSY, WINDSHIELD SUPPORT, RH

main56306-90302iBJ4#198008-198410

56307HINGE SUB-ASSY, WINDSHIELD SUPPORT, LH

main56307-90302iBJ4#198008-198410

56313RAIL, WINDSHIELD FRAME, UPPER

main56313-90300iBJ4#..TPC198008-198410

main56313-90800iBJ4#..TPC198008-198410

FOLDING TYPE

56365PROTECTOR, WINDSHIELD FRAME UPPER CORNER, RH

main56365-90800iBJ4#..TPC198008-198410

56366PROTECTOR, WINDSHIELD FRAME UPPER CORNER, LH

main56366-90800iBJ4#..TPC198008-198410

56457BRACKET, WINDSHIELD CATCH, UPPER

main56457-60010×2iBJ4#198008-198410

9011906086

main90119-06086

9015980010

main90159-80010

9016850015

main90168-50015

9166540616

main91665-40616

20 parts on this diagram · 1 diagram in section
