SWITCH & RELAY & COMPUTER

0001 1E/G,T/M,T/F 0002 1E/G,T/M,T/F 0003 1E/G,T/M,T/F 0004 1ENGINE ROOM 0005 1ENGINE ROOM 0006 1ENGINE ROOM 0007 1INPANE & COWL 0008 1INPANE & COWL 0009 1INPANE SW 0010 1IG. SW. & COMBINATION SW. 0011 1DOOR, ROOF & FLOOR 0012 1REAR BODY 0013 1BLOCK METER 0014 1TILT SW.

28621RESISTOR, GLOW PLUG

main28621-57011i3B..BU100,105,120,140,145199505-199906

8301

83420GAGE ASSY, WATER TEMPERATURE SENDER

main83420-16040iBU10#,112,12#,13#,14#,162,172,182,202,212,222199506-199906

main83420-16040iBU10#,112,12#,132,14#,162,172,182,202,212,222199505-199905

main83420-20030iBU10#,112,12#,132,14#,162,172,182,202,212,222199505-199506

sub83420-16040

main83420-20040iRZU100,140199505-200005

main83420-36010iBU297199701-199905

main83420-89101iXZU130199510-199708

subS8342-01060

main83420-89102iXZU130,140199708-199905

subS8342-01240

83420AGAGE ASSY, OIL TEMPERATURE SENDER

main83420-36010iBU102,172..IV4199507-199905

83530SWITCH ASSY, OIL PRESSURE (FOR ENGINE)

main83530-14070iBU10#,112,12#,13#,14#,162,172,182,202,212,222,297199505-199803

sub83530-28010

main83530-28010iBU10#,112,120,13#,14#,162,172,182,202,212,222,297199803-199906

main83530-28020iRZU100,140199803-200005

main83530-30090iRZU100,140199505-199803

sub83530-60020

main83530-30100iBU10#,112,12#,13#,14#,162,172,182,202,212,222,297199505-199803

sub83530-60010

main83530-60010iBU10#,112,120,13#,14#,162,172,182,202,212,222,297199803-199906

main83530-89103iXZU130199510-199905

main83530-89105iXZU130,140199510-199905

sub83530-E0180

84210SWITCH ASSY, BACK-UP LAMP

main84210-12040iBU142,212,222..6F199708-199906

sub84210-52050

main84210-60030iBU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..5F199505-200005

84222SWITCH, TRANSFER INDICATOR, NO.1

main84222-12010iBU172,182..T4199505-199906

84222BSWITCH, TRANSFER INDICATOR, NO.2

main84222-60080iBU162,172,182,297199505-199906

sub84222-60081

84225ASWITCH, SHIFT POSITION

main84225-35010iBU212..30T;BU212,222..TD..6F;BU102,107,112,122,13#,142,147,162,172,182,202,212,222,XZU130,140..(DSL,TD)..5F199505-199906

84540SWITCH ASSY, NEUTRAL START

main84540-36030iBU132..TL4..5F;BU102,107,112,132,142,147,212..4FC199505-199906

main84540-65010iBU297199701-199905

84540CSWITCH ASSY, NEUTRAL (FOR EXHAUST BRAKE)

main84540-36090iBU132..TL4..5F;BU132..CBU..5F;BU132..(T3,T4)..IV3;BU10#,112,12#,137,14#,162,172,182,202,212,222,XZU130,140..MTM..(DSL,TD)199505-199906

89422ASENSOR, WATER TEMPERATURE

main89422-20010iBU102,142..LPGB199605-199905

main89422-20010iRZU100..LPGB199905-200005

main89422-20010iBU10#,112,12#,13#,14#,162,172,182,202,212,222..DSL,TD199505-199906

main89422-36010iBU102..DSL..5F;BU102..T2..4FC;BU102..30T..4FC;BU100,105,107,112,120,13#,14#,162,172,182,202,212,222..DSL,TD199708-199906

sub89422-37030

main89422-36010iBU102..LPGB199708-199905

sub89422-37030

main89422-36010iBU102..4FC199905-199906

sub89422-37030

main89422-36010iRZU100..LPGB199905-200005

sub89422-37030

89425SENSOR, EXHAUST GAS TEMPERATURE

main89425-39495iRZU100,140199505-199712

main89425-80030iBU102,142..LPGB199605-199712

89429SENSOR, OIL TEMPERATURE

main89410-89101iXZU130,140199510-199905

subS8943-01070

main89422-20010iBU297199505-199906

89452ASENSOR, THROTTLE POSITION

main89452-22090iBU102,142,RZU100..LPGB199605-200005

89491SENSOR, ENGINE OIL LEVEL

main89491-37010iRZU100,140199505-199711

sub89491-37011

main89491-37011iRZU100,140..EFI,LPG199711-200005

main89491-37020iBU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100..DSL,LPGB,TD199505-200005

main89491-89101iXZU130,140199510-199905

subS8346-01211

89491AGASKET, ENGINE OIL LEVEL SENSOR

main89493-60010iRZU100..EFI,LPG;BU142,RZU140..EFI,LPGB199711-200005

main90430-27001iBU10#,112,12#,13#,14#,162,172,182,202,212,222..DSL,TD199505-199906

8271132060WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-32060

8271136080WIRE, FUSE TO FUSE(FOR COMBUSTION HEATER)

main82711-36080

9003105001

main90031-05001

9003105010

main90031-05010

9003401011

main90034-01011

9003430020

main90034-30020

9003430041

main90034-30041

9003461043

main90034-61043

9020210012

main90202-10012

9030121003

main90301-21003

9040410024

main90404-10024

9043008252

main90430-08252

9043012221

main90430-12221

9043018008

main90430-18008

9165140825

main91651-40825

9165141020

main91651-41020

9165160614

main91651-60614

9165160616

main91651-60616

35 parts on this diagram · 14 diagrams in section
