CLUTCH PEDAL & FLEXIBLE HOSE

0001 1 0002 1

31301PEDAL SUB-ASSY, CLUTCH

main31301-25090iTRY230..5F202108-202509

31301BCUSHION, NO.1(FOR CLUTCH PEDAL)

main90541-06036iGDY231,281..5F202108-202509

31301CBUSH(FOR CLUTCH PEDAL)

main90386-13015iGDY231,281..5F202108-202509

31301FBOLT(FOR CLUTCH PEDAL STOPPER)

main91551-80825iGDY231,281..5F202108-202509

31301JNUT(FOR CLUTCH PEDAL STOPPER)

main94130-60800iGDY231,281..5F202108-202509

31301PBUSH(FOR CLUTCH PEDAL TURNOVER)

main90389-06055iGDY231,281..5F202108-202509

31301RSPRING, COMPRESSION(FOR TURNOVER SPRING SEAT)

main31316-25020iGDY231,281..5F202108-202509

main31316-25030iTRY230..5F202108

31305BRACKET SUB-ASSY, CLUTCH PEDAL

main31305-25010iGDY231,281..5F202108-202509

31321PAD, CLUTCH PEDAL

main31321-52020iGDY231,281..5F202108-202509

31324SHAFT, CLUTCH PEDAL

main91552-81060iGDY231,281..5F202108-202509

31324ACOLLAR, CLUTCH PEDAL SHAFT

main90387-10003iGDY231,281..5F202108-202509

31353HOLDER, CLUTCH PEDAL SPRING

main31353-37010iGDY231,281..5F202108-202509

31358CAP, OVER CENTER SPRING

main31358-42010iGDY231,281..5F202108-202509

31453APIN, W/HOLE(FOR CLUTCH MASTER CYLINDER PUSH ROD CLEVIS)

main90240-08006iTRY230..5F202108-202509

31453BBUSH(FOR CLUTCH MASTER CYLINDER PUSH ROD CLEVIS)

main90386-08002iGDY231,281..5F202108-202509

8401

9046816032

main90468-16032

91611B0816

main91611-B0816

9415181001

main94151-81001

9616000600

main96160-00600

20 parts on this diagram · 2 diagrams in section
