THROTTLE LINK & VALVE LEVER (ATM)

0001 1A45DL,A45DF,A44DE,A45DE 0003 1A340E 0004 1A45DF,A44DE,A45DE 0006 1A340E 0007 1A340E,A340F 0008 1A45DL,A45DF 0009 1A45DL,A44DE,A45DE

35501ROD SUB-ASSY, PARKING LOCK

main35501-26020iLH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD)198908-199907

main35501-30010iKZH10#,11#,120,13#,LH100,120..4FC199010-199608

main35501-60010iKZH10#,11#,120,13#199907-200408

35505LEVER SUB-ASSY, MANUAL VALVE

main35505-22040iLH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD)198908-199907

main35505-30020iKZH10#,11#,120,13#199907-200408

main35505-30021iKZH10#,11#,120,13#,LH100,120..4FC199010-199907

35506CPIN, SLOTTED SPRING (FOR MANUAL VALVE LEVER SHAFT)

main90254-04011iKZH10#,11#,120,13#,LH100,102,103,107,113,119,120,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC198908-199907

35506FSEAL, OIL (FOR MANUAL VALVE LEVER SHAFT)

main90311-11003×2iTRH12#..4FC199907-200501

main90311-12002×2iKZH10#,11#,120,13#199907-200408

35506HSPACER (FOR MANUAL VALVE LEVER SHAFT)

main90560-20003iRZH101,111199907-200208

main90560-20006iKZH10#,11#,120,13#,LH100,120..4FC199010-199907

main90560-20025iRZH102,112,125,183..4FC200302-200308

35556SHAFT, PARKING LOCK PAWL

main35556-26010iLH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD)198908-199907

main35556-30020iKZH10#,11#,120,13#199907-200408

35556ERING, E (FOR PARKING LOCK PAWL SHAFT)

main90523-08021iKZH10#,11#,120,13#,LH100,102,103,107,113,119,120,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC198908-199907

35557PAWL, PARKING LOCK

main35557-26010iLH100,102,103,113,123,RZH10#,111,112,133..4FC..(CBR,DSL,EFI,TD)198908-199511

main35557-26020iRZH101,111199907-200208

main35557-26030iLH107,119,129..4FC198908-199603

main35557-26031iLH119,129..4FC199603-199608

main35557-26040iLH119,129,162,17#,18#..4FC199608-199907

main35557-30020iKZH10#,11#,120,13#,LH100,120..4FC199010-199608

main35557-60020iKZH10#,11#,120,13#199907-200408

35557ASPRING, TORSION (FOR PARKING LOCK PAWL)

main90508-21001iRZH101,111199907-200208

main90508-21002iKZH10#,11#,120,13#199907-200408

35561SHAFT, MANUAL VALVE LEVER

main35561-30070iKZH10#,11#,120,13#,LH100,120..4FC199010-199907

main35561-40010iRZH102,112,125,183..4FC199907-200308

35572LEVER, TRANSMISSION CONTROL SHAFT, RH

main35572-26010iLH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD)198908-199907

main35572-26020iKZH10#,11#,120,13#199907-200408

35595BRACKET, PARKING LOCK PAWL

main35595-26010iLH107,119,129,162,17#,18#..4FC198908-199907

main35595-30010iKZH10#,11#,120,13#,LH100,120..4FC199010-199608

main35595-40010iTRH12#..4FC199907-200501

main35595-60010iKZH10#,11#,120,13#199907-200408

9010106024

main90101-06024

9411050800

main94110-50800

9451200800

main94512-00800

9454200600

main94542-00600

16 parts on this diagram · 7 diagrams in section
