CAUTION PLATE

0001 1��������(1/2) 0002 1��������,���������,����

11284APLATE, ENGINE BOLT INFORMATION

main11284-75010i2TZFE..TCR1#,2#199201-199308

main11284-75020i2TZFE..TCR1#,2#199308-199401

11289BLABEL, SPARK PLUG NOTICE

main11289-16010i2TZFE..TCR1#,2#199201-199505

11291BPLATE, ENGINE NAME

main11291-64070i3CT..CXR1#,2#199201-199209

11294ALABEL, TURBOCHARGER INFORMATION

main11294-64040i3CT#..CXR1#,2#199201-199908

sub11294-64070

11296CLABEL, ENGINE SERVICE INFORMATION

main11296-55020i3CT..CXR1#,2#199201-199308

main11296-64010i3CTE..CXR1#,2#199308-199908

main11296-76012i2TZFE..TCR1#,2#199201-199408

main11296-76040i2TZFE..TCR1#,2#199408-199505

sub11296-76050

main11296-76050i2TZFE..TCR1#,2#199505-199608

main11296-76060i2TZFE..TCR1#,2#199608-199912

11297DLABEL, ENGINE STARTING INFORMATION

main11297-64010i3CT#..CXR1#,2#199201-199312

13564LABEL, TIMING BELT REPLACEMENT INFORMATION

main13564-10010iCXR1#,2#..AERAS,D,F,G,GLUX,X,XLUX199201-199908

15369BLABEL, ENGINE OIL NOTICE

main15369-54010i3CTE..CXR1#,2#199201-199501

CRANKCASE

main15369-54010i3CTE..CXR1#,2#199501-199812

main15369-64010i3CTE..CXR1#,2#199812-199908

main15369-76020i3CT#,2TZFE..CXR1#,2#,TCR1#,2#199201-199501

17700RLABEL, AIR CLEANER INFORMATION

main11296-55020i3CTE..CXR1#,2#199406-199505

main11296-64030i3CTE..CXR1#,2#199505-199707

sub11296-64031

main11296-64031i3CTE..CXR1#,2#199707-199908

17791ALABEL, MAINTENANCE INFORMATION

main17791-55010i3CT#..CXR1#,2#199201-199908

17792CLABEL, ENGINE VACUUM HOSE INFORMATION

main17792-76021i2TZFE..TCR1#,2#199201-199501

main17792-76022i2TZFE..TCR1#,2#199501-199608

11 parts on this diagram · 2 diagrams in section
