REAR SPRING & SHOCK ABSORBER

0001 1 0002 1

42304CARRIER SUB-ASSY, REAR AXLE, RH

main42313-28010iCXR11,21,TCR11,21..G,GLUX199201-199608

main42313-28020iCXR11,21,TCR11,21..G199201-199308

main42313-28020iTCR11,21..S199201-199608

main42313-28020iCXR11,21,TCR11,21199608-199912

main42313-28030iTCR11,21..S199201-199308

42305CARRIER SUB-ASSY, REAR AXLE, LH

main42314-28010iCXR11,21,TCR11,21..G,GLUX199201-199608

main42314-28020iCXR11,21,TCR11,21199201-199608

main42314-28020iTCR11,21..S199201-199308

main42314-28020iCXR11,21,TCR11,21199608-199912

main42314-28030iTCR11,21..S199201-199308

48190RCAM ASSY, CAMBER ADJUST

main48190-28010iCXR11,21,TCR11,21199201-199912

48198RCAM, REAR SUSPENSION CAMBER ADJUST, NO.2

main48198-14010iCXR11,21,TCR11,21199201-199912

UPR CONTROL ARM

sub48198-50011

main48198-28010iCXR11,21,TCR11,21199201-199912

LWR CONTROL ARM

48231ASPRING, COIL, REAR RH

main48231-28310iTCR21..S199201-199308

main48231-28310iTCR21..S199201-199308

main48231-28320iCXR21,TCR21..G199201-199308

main48231-28330iTCR11..S199201-199308

main48231-28340iCXR11,TCR11..G199201-199308

main48231-28350iTCR11..S199201-199308

main48231-28350iTCR11..S199201-199308

main48231-28360iCXR11,TCR11..G199201-199308

main48231-28360iTCR11..S199201-199308

main48231-28370iTCR11..G199201-199308

main48231-28410iCXR10..D;TCR10..F199201-199210

main48231-28420iCXR10..F;TCR10..X199201-199210

sub48231-28500

main48231-28430iTCR10..X199201-199210

sub48231-28500

main48231-28430iTCR10..X199201-199210

sub48231-28500

main48231-28430iCXR10..D;TCR10..F199210-199308

sub48231-28500

main48231-28440iTCR10..X;CXR10..F,X199201-199210

sub48231-28430

main48231-28440iTCR10..X;CXR10..F,X199210-199308

sub48231-28430

main48231-28450iCXR20..D199201-199308

main48231-28460iCXR20,TCR20..F,X199201-199308

sub48231-28490

main48231-28490iCXR20,TCR20..X199201-199308

main48231-28530iCXR20..X;TCR20..AERAS,ELU,XLUX199308-199912

main48231-28530iTCR20199308-199912

main48231-28530iCXR10..ELU,X,XLUX199308-199908

main48231-28540iCXR20..X;TCR20..ELU199308-199912

sub48231-28530

main48231-28540iCXR20..AERAS,ELU,XLUX199501-199908

sub48231-28530

main48231-28540iTCR20199308-199912

sub48231-28530

main48231-28550iCXR11,TCR11..G199308-199912

main48231-28560iTCR21199308-199912

sub48231-28550

main48231-28560iCXR21..GLUX199501-199801

sub48231-28550

main48231-28560iCXR21..G199308-199908

sub48231-28550

main48231-28680iCXR10,TCR10..F,X199308-199912

main48231-28690iCXR10,TCR10..X199308-199912

sub48231-28530

main48231-28690iCXR20..F;TCR20..X;CXR10,TCR10..AERAS,ELU,XLUX199308-199912

sub48231-28530

main48231-28700iCXR11,TCR11..G199308-199912

sub48231-28550

main48231-28710iCXR11199308-199908

sub48231-28550

main48231-28710iCXR11199308-199908

sub48231-28550

main48231-28710iCXR21,TCR21..GLUX199501-199801

sub48231-28550

main48231-28710iTCR21..G199308-199912

sub48231-28550

48231BSPRING, COIL, REAR LH

main48231-28310iTCR21..S199201-199308

main48231-28310iTCR21..S199201-199308

main48231-28320iCXR21,TCR21..G199201-199308

main48231-28330iTCR11..S199201-199308

main48231-28340iCXR11,TCR11..G199201-199308

main48231-28350iTCR11..S199201-199308

main48231-28350iCXR11,TCR11..G199201-199308

main48231-28360iTCR11..S199201-199308

main48231-28360iTCR11..S199201-199308

main48231-28370iTCR11..G199201-199308

main48231-28410iCXR10..D;TCR10..F199201-199210

main48231-28420iCXR10..F;TCR10..X199201-199210

sub48231-28500

main48231-28430iCXR10..D;TCR10..F199201-199210

sub48231-28500

main48231-28430iCXR10..D;TCR10..F199201-199210

sub48231-28500

main48231-28430iCXR10..D;TCR10..F199210-199308

sub48231-28500

main48231-28440iTCR10..X;CXR10..F,X199201-199210

sub48231-28430

main48231-28440iTCR10..X;CXR10..F,X199210-199308

sub48231-28430

main48231-28450iCXR20..D199201-199308

main48231-28460iCXR20,TCR20..F,X199201-199308

sub48231-28490

main48231-28490iCXR20,TCR20..X199201-199308

main48231-28530iCXR20..X;TCR20..AERAS,ELU,XLUX199308-199912

main48231-28530iTCR20199308-199912

main48231-28530iCXR10..ELU,X,XLUX199308-199908

main48231-28540iTCR20..ATM..(X,XLUX)199308-199912

sub48231-28530

main48231-28540iCXR20..AERAS,ELU,XLUX199501-199908

sub48231-28530

main48231-28540iCXR20..X;TCR20..ELU199308-199912

sub48231-28530

main48231-28550iCXR11,TCR11..G199308-199912

main48231-28560iCXR21..G199308-199908

sub48231-28550

main48231-28560iTCR21199308-199912

sub48231-28550

main48231-28560iCXR21..GLUX199501-199801

sub48231-28550

main48231-28680iCXR10,TCR10..F,X199308-199912

main48231-28690iCXR10,TCR10..X199308-199912

sub48231-28530

main48231-28690iCXR20..F;TCR20..X;CXR10,TCR10..AERAS,ELU,XLUX199308-199912

sub48231-28530

main48231-28700iCXR11,TCR11..G199308-199912

sub48231-28550

main48231-28710iCXR21..G199308-199908

sub48231-28550

main48231-28710iCXR11199308-199908

sub48231-28550

main48231-28710iTCR21..G199308-199912

sub48231-28550

main48231-28710iCXR21,TCR21..GLUX199501-199801

sub48231-28550

48257CINSULATOR, REAR COIL SPRING, UPPER RH

main48257-28020iCXR10,20,TCR10,20199201-199912

main48257-28030iCXR11,21,TCR11,21199201-199912

48258BINSULATOR, REAR COIL SPRING, LOWER RH

main48258-28020iCXR10,20,TCR10,20199201-199912

main48258-28030iCXR11,21,TCR11,21199201-199912

48258CINSULATOR, REAR COIL SPRING, LOWER LH

main48258-28020iCXR10,20,TCR10,20199201-199912

main48258-28030iCXR11,21,TCR11,21199201-199912

48259AINSULATOR, REAR COIL SPRING, UPPER LH

main48257-28020iCXR10,20,TCR10,20199201-199912

main48257-28030iCXR11,21,TCR11,21199201-199912

48341ABUMPER, REAR SPRING, NO.1 RH

main48306-28010iCXR11,21,TCR11,21199201-199912

main48341-28062iCXR10,20,TCR10,20199201-199210

main48341-28080iCXR10,20,TCR10,20199210-199912

48341BBUMPER, REAR SPRING, NO.1 LH

main48306-28010iCXR11,21,TCR11,21199201-199912

main48341-28062iCXR10,20,TCR10,20199201-199210

main48341-28080iCXR10,20,TCR10,20199210-199912

48409CAM SUB-ASSY, REAR SUSPENSION TOE ADJUST

main48409-28020iCXR11,21,TCR11,21199201-199912

48530ABSORBER ASSY, SHOCK, REAR RH

main48531-80123iCXR11,21,TCR11,21199201-199806

sub48531-80659

main48531-80124iCXR10,TCR10199201-199308

sub48531-80127

main48531-80127iCXR20,TCR20199201-199806

sub48531-80660

main48531-80659iCXR11,21,TCR11,21199806-199912

main48531-80660iCXR10,20,TCR10,20199806-199912

48530GCUSHION, REAR SHOCK ABSORBER, NO.1

main90540-10004iCXR10,20,TCR10,20199201-199912

48530JRETAINER, CUSHION, NO.1(FOR REAR SHOCK ABSORBER)

main90948-02132iCXR10,20,TCR10,20199201-199912

48530PRETAINER, CUSHION, NO.2(FOR REAR SHOCK ABSORBER)

main90948-02133iCXR10,20,TCR10,20199201-199912

main90948-02134iCXR11,21,TCR11,21199201-199912

sub90948-02166

48540ABSORBER ASSY, SHOCK, REAR LH

main48531-80123iCXR11,21,TCR11,21199201-199806

sub48531-80659

main48531-80124iCXR10,TCR10199201-199308

sub48531-80127

main48531-80127iCXR10,20,TCR10,20199201-199806

sub48531-80660

main48531-80659iCXR11,21,TCR11,21199806-199912

main48531-80660iCXR10,20,TCR10,20199806-199912

48702BUSH SUB-ASSY, UPPER CONTROL ARM

main48702-28080iCXR10,20,TCR10,20199201-199912

48702CBUSH SUB-ASSY, LOWER CONTROL ARM

main48702-28060iCXR11,21,TCR11,21199201-199303

sub48702-28061

sub90105-12267

main48702-28061iCXR11,21,TCR11,21199303-199912

main48702-28070iCXR10,20,TCR10,20199201-199912

main48704-28020iCXR11,21,TCR11,21199201-199303

sub48704-28021

sub90105-12267

main48704-28021iCXR11,21,TCR11,21199303-199912

48720ARM ASSY, LOWER CONTROL, RH

main48720-28070iCXR11,21,TCR11,21199201-199308

sub48720-28071

sub48720-28H00

sub48720-28H01

main48720-28071iCXR11,21,TCR11,21199308-199912

48730ARM ASSY, LOWER CONTROL, LH

main48730-28070iCXR11,21,TCR11,21199201-199308

sub48730-28071

sub48730-28H00

sub48730-28H01

main48730-28071iCXR11,21,TCR11,21199308-199912

48770AARM ASSY, UPPER CONTROL, REAR RH

main48710-28070iTCR10,20199201-199608

sub48710-28071

main48710-28071iCXR10,20,TCR10,20199608-199912

main48710-28100iCXR10,20199201-199304

main48770-28010iCXR11,21,TCR11,21199201-199912

48790ARM ASSY, UPPER CONTROL, REAR LH

main48710-28070iCXR10,20,TCR10,20199201-199608

sub48710-28071

main48710-28071iCXR10,20,TCR10,20199608-199912

main48710-28100iCXR10,20199201-199304

main48790-28010iCXR11,21,TCR11,21199201-199912

9010512267

main90105-12267

9010516036

main90105-16036

9011908543

main90119-08543

9017912027

main90179-12027

9017914007

main90179-14007

9017916005

main90179-16005

9017918007

main90179-18007

9094802135

main90948-02135

9094802136

main90948-02136

9418461000

main94184-61000

9462211600

main94622-11600

35 parts on this diagram · 2 diagrams in section
