RADIATOR & WATER OUTLET

0001 1 0002 1 0003 1 0004 1 0005 1 0006 1 0007 1 0008 1 0009 1�������� 0010 1 0011 1 0012 1 0013 1 0014 1 0015 1 0016 1 0017 1 0018 1

1601

16361FAN

main16361-70020i3CT#..CXR1#,2#199201-199908

main16361-76060i2TZFE..TCR1#,2#199201-199912

16381BAR, FAN BELT ADJUSTING

main16381-64060i3CT..CXR1#,2#199201-199308

main16381-64100i3CTE..CXR1#,2#199308-199501

main16381-64120i3CTE..CXR1#,2#199501-199908

main16381-76040i2TZFE..TCR1#,2#199201-199508

main16381-76060i2TZFE..TCR1#,2#199508-199707

main16381-76061i2TZFE..TCR1#,2#199707-199912

16385SLIDER, FAN BELT ADJUSTING

main16385-76020i2TZFE..TCR1#,2#199201-199908

main16385-76030i2TZFE..TCR1#,2#199508-199912

16630DPULLEY ASSY, IDLER

main16630-64010i3CT#..CXR1#,2#199201-199501

16908HOUSING SUB-ASSY, EQUIPMENT DRIVE

main16908-64010i3CT..CXR1#,2#199201-199308

main16908-64020i3CTE..CXR1#,2#199308-199501

main16908-64030i3CTE..CXR1#,2#199501-199908

main16908-76012i2TZFE..TCR1#,2#199201-199912

16982INSULATOR, EQUIPMENT DRIVE HOUSING, NO.1

main16982-76011i3CT#..CXR1#,2#199201-199912

main16982-76020i2TZFE..TCR1#,2#199201-199912

16983INSULATOR, EQUIPMENT DRIVE HOUSING, NO.2

main16983-76012i2TZFE..TCR1#,2#199201-199912

16984STAY, EQUIPMENT DRIVE HOUSING, NO.1

main16984-64010i3CT#..CXR1#,2#199201-199908

main16984-76010i2TZFE..TCR1#,2#199201-199912

16985STAY, EQUIPMENT DRIVE HOUSING, NO.2

main16985-64010i3CT#..CXR1#,2#199201-199908

main16985-76011i2TZFE..TCR1#,2#199201-199912

16986STAY, EQUIPMENT DRIVE HOUSING, NO.3

main16986-64010i3CT#..CXR1#,2#199201-199908

main16986-76012i2TZFE..TCR1#,2#199201-199707

main16986-76050i2TZFE..TCR1#,2#199707-199912

16987STAY, EQUIPMENT DRIVE HOUSING, NO.4

main16987-64010i3CT#..CXR1#,2#199201-199908

main16987-76010i2TZFE..TCR1#,2#199201-199912

16988STAY, EQUIPMENT DRIVE HOUSING, NO.5

main16988-64010i3CT#..CXR1#,2#199201-199908

main16988-76010i2TZFE..TCR1#,2#199201-199912

16989DAMPER, EQUIPMENT DRIVE HOUSING DYNAMIC

main16989-64010i3CT#..CXR1#,2#199201-199908

main16989-76030i2TZFE..TCR1#,2#199707-199912

16991PULLEY, EQUIPMENT DRIVE

main16991-64010i3CT..CXR1#,2#199201-199308

main16991-64020i3CTE..CXR1#,2#199308-199501

main16991-64030i3CTE..CXR1#,2#199501-199908

main16991-76020i2TZFE..TCR1#,2#199201-199612

sub16991-76021

main16991-76021i2TZFE..TCR1#,2#199612-199912

1903

3702

4502

4503

9011908735

main90119-08735

9017906080

main90179-06080

9017908040

main90179-08040

9017910015

main90179-10015

9017910033

main90179-10033

9017910114

main90179-10114

9020110320

main90201-10320

9038910017

main90389-10017

9090107001

main90901-07001

9165160820

main91651-60820

29 parts on this diagram · 18 diagrams in section
